Specifications
HZS100 Modular Portable Concrete Batching Plant for sale1.Compact structure and all ready functions
2.Convenient movement
HZS100 Modular Portable Concrete Batching Plant for sale
1.Excellent mixing performance
Mixer consoles with the German technology. Strong mixing performance,mix homogeneous and rapid,high productivity. For dry, rigid, plastic and all kinds of concrete proportion of all can reach the good mixing effect.
2.Highest reliable performance
All electrical components of the control system are imported components, greatly reduce the equipment failure.
3.Unique no-sticky shaft technology
Through the unique design and reasonable allocation of the mixing arms, mixing vanes, material feeding points, material feeding order ect parts and movements, solve the concrete sticky shaft problem, also reduce the labor intensity.
4. Accurate measurement accuracy
Adopt computer and meter contrlo mode, fast calculatino speed, short reponse time;Cooperate with the patented technology of clicking point filling and automatic buckle says function, make measruement accuracy achives dynamic and more than national measurement standards.
Model |
HZN40 |
HZS50 |
HZS75 |
HZS100 |
|
Capacity (m3/h) |
40 |
50 |
75 |
100 |
|
Concrete Mixer |
Model |
JN750 |
JS1000 |
JS1500 |
JS2000 |
Mixing Power(kw) |
20 |
2*18.5 |
2*30 |
2*37 |
|
Discharge Volume (m3) |
0.75 |
1 |
1.5 |
2 |
|
Aggregate Diameter(mm) |
≤60/80 |
≤60/80 |
≤60/80 |
≤60/80 |
|
Batching Hopper |
Volume(m3) |
4 |
8 |
8 |
8 |
Motor Power (kw) |
7.5 |
18.5 |
22 |
30 |
|
Weighing Range |
Aggregate (kg) |
1500±2% |
2000±2% |
3000±2% |
3000±2% |
Cement (kg) |
400±1% |
500±1% |
800±1% |
800±1% |
|
Coal Ash(kg) |
150±1% |
200±1% |
400±1% |
||
Water (kg) |
Turbine flowmeter |
200±1% |
300±1% |
400±1% |
|
Addictive(kg) |
20±1% |
20±1% |
30±1% |
30±1% |
|
Discharging height(m) |
3.8 |
3.8 |
3.8 |
3.8 |
- Technical support online service provided.
- Technical files service provided.
- On-site training service provided.
- Spare parts replacement and repair service provided
