Help CenterCement Screw Conveyors Concrete Plant Brick Making Line for Cement Transfer 219mm* 12m
Related Products
-
Discharging Belt Conveyor for Concrete Batching Plant 12m*800mmNegotiableMOQ: 1 Set -
High Temperature Conveyor Belt for Middle EastNegotiableMOQ: 100 Sets
-
Concrete Bathing Plant Belt ConveyorUS$ 5,578 - 7,812MOQ: 1 Set
-
High Quality Screw Conveyor CustomizedUS$ 1 - 1,327MOQ: 1 Set
-
Best Quality Cement Auger Screw Conveyor Price,screw Machine PriceUS$ 1 - 1,327MOQ: 1 Set
Specifications
cement screw conveyors concrete plant brick making line for cement transfer 219mm*12m1high quality steel pipe
2avoid blocking
cement screw conveyors concrete plant brick making line for cement transfer 219mm* 12m
Characteristics
1. Adopt high-quality steel pipe with good integral rigidity.
2. Adopt double-pitch paddles, which decrease the compression degree of material when being transported, and avoid blocking.
3. Adopt high-quality reducer with heavy-duty design, large torque and low noise.
4. Adopt optional universal ball joint, which facilitates installation, adjustment and steering.
5. Inlet equipped with high quality middle-hoisting bearing and tail bearing.
6. Sufficient spare parts with complete specification.
7. Large stock for common diameter of 165,219,273, 323 and 407, and dimension & angle can be customized according to your requirement.
8. Assembled by standard parts and components, which makes it convenient for transportation.
9. Adopt Simens motor
Diameter 168mm | |||
Length (m) |
reducer |
speed ratio |
motor power (kw) |
3 |
SD1500 |
5/28 |
4 |
4 |
SD1500 |
5/28 |
4 |
5 |
SD1500 |
5/28 |
4 |
6 |
SD1500 |
5/28 |
5.5 |
7 |
SD1500 |
5/28 |
5.5 |
8 |
SD1500 |
5/28 |
5.5 |
9 |
SD1500 |
5/28 |
5.5 |
10 |
SD1500 |
5/28 |
7.5 |
11 |
SD1500 |
5/28 |
7.5 |
12 |
SD1500 |
5/28 |
7.5 |
13 |
SD1500 |
5/28 |
7.5 |
14 |
SD1500 |
5/28 |
7.5 |
Diameter 219mm | |||
Length (m) |
reducer |
speed ratio |
motor power (kw) |
3 |
SD1500 |
5/28 |
4 |
4 |
SD1500 |
5/38 |
5.5 |
5 |
SD1500 |
5/38 |
5.5 |
6 |
SD1500 |
5/38 |
7.5 |
7 |
SD1500 |
5/38 |
7.5 |
8 |
SD1500 |
5/38 |
7.5 |
9 |
SD1500 |
5/42 |
11 |
10 |
SD1500 |
5/42 |
11 |
11 |
SD1500 |
5/42 |
11 |
12 |
SD1500 |
5/42 |
11 |
13 |
SD1500 |
5/42 |
15 |
14 |
SD1500 |
5/42 |
15 |
Diameter 273mm | |||
Length (m) |
reducer |
speed ratio |
motor power (kw) |
3 |
SD2000 |
7/38 |
5.5 |
4 |
SD2000 |
7/38 |
7.5 |
5 |
SD2000 |
7/38 |
7.5 |
6 |
SD2000 |
7/42 |
11 |
7 |
SD2000 |
7/42 |
11 |
8 |
SD2000 |
7/42 |
11 |
9 |
SD2000 |
7/42 |
15 |
10 |
SD2000 |
7/42 |
15 |
11 |
SD3000 |
7/42 |
15 |
12 |
SD3000 |
7/42 |
15 |
13 |
SD3000 |
7/48 |
18.5 |
14 |
SD3000 |
7/48 |
18.5 |
Diameter 323mm | |||
Length(m) |
reducer |
speed ratio |
motor power (kw) |
3 |
SD2000 |
7/38 |
7.5 |
4 |
SD2000 |
7/42 |
11 |
5 |
SD2000 |
7/42 |
11 |
6 |
SD3000 |
10/42 |
15 |
7 |
SD3000 |
10/42 |
15 |
8 |
SD3000 |
10/48 |
18.5 |
9 |
SD3000 |
10/48 |
18.5 |
10 |
SD3000 |
10/48 |
18.5 |
11 |
SD3000 |
10/48 |
22 |
12 |
SD3000 |
10/48 |
22 |
13 |
SD3000 |
10/48 |
22 |
14 |
SD3000 |
10/48 |
22 |
Spare parts avaliable :
1. Technical support online service provided.
2. Technical files service provided.
3. On-site training service provided.
4. Spare parts replacement and repair service provided
5. customize service
Taian Shizhe Trading Company Limited established in 2011 is engaged in import and export trading. We mainly conduct business including domestic and foreign trading, such as concrete mixing plant, concrete mixers, Chinese-foreign cooperative producing, and entrecote trading. Our manufacture mainly produce concrete batching plant, asphalt plant, brick production line and related equipments of construction. Concrete mixer, screw conveyor, cement silo and accessories have always been our hottest products for export. Besides, the small concrete tools such as concrete vibrator, concrete vibratory screed, tamping rammer, plate compactor, concret cutter also belong to hot product. Besides, we purchase kinds of products in China for our customers.
1. Q: Where is your customers from?
A: Our company is extending the trade scale at present. We have clients all over the world, such as Russia, Australia, Singapore,New Zealand, Canada, Malta, Turkey, Ukraine, Mongolia, Belarus, Qatar, Mozambique etc, and won the trust of the customers with good reputation. We make active effort to promoting the modernization construction of our country, encouraging the economic and technical communication with the world, and enhance the friendship with people all over the world.
2. Do you provide customerize service?
Yes, we do. we can customize different products according to our customers' requirement.
3.Do you provide sample?
Yes, for most of our products, we provide sample for customers' referene. But, for the whole plant, we can not provide. we welcome our customers to visit us very much.
4. Q: What is your MOQ ?
A: Our MOQ is one set.
If you have any further question, please do feel free to contact me.
