Specifications
MC1200 ready mixed concrete batching plant wet mix dry mix1convenient to transport
2require no pure foundation
3 easy to in
MC1200 ready mixed concrete batching plant wet mix dry mix
Introduction:
With a semi-mobile batching plant, it is possible to produce concrete at the same place over a longer period and then move on to new jobs. The robust container frame is equipped with a draw hook, which allows the batching plant to be pulled on to a lorry with a hook hoist. Alternatively, it can be lifted on to a lorry with a crane.
The batching plants require no poured foundation and they can be placed on any even surface. You can start producing concrete within a few hours after the batching plant is erected. All you have to do is connect electricity, water and any other equipment, and fill sand and gravel in the hoppers.
The powerful pan mixer is equipped with adjustable mixing arms with robust mixing shovels and side scrapers, providing a short cycle time and a high, uniform concrete quality. A high quality is also ensured by the integrated control system, which controls and monitors all processes and connected equipment, e.g. a belt conveyor and/or cement silos.
A hook container model is a profitable investment which will soon pay for itself and return a profit. All wearing parts are produced in robust materials and can be replaced separately, which minimizes operating costs. There is free access to all of the plant functions, facilitating daily cleaning, maintenance and service.
Technical Parameter
NO. |
Item |
Specification |
||||
1 |
Product model |
concrete mixing plant |
||||
2 |
Principle for design and production
|
Domestic standard: concrete mixing plant:GB10171-2005 concrete mixer: GB/T9142-2000 |
||||
3 |
Working Environment
|
1) working environment 10C~400C; 2) relative humidity no more than 90%; 3) maximum snow load 800Pa; 4) maximum wind load 700Pa; 5) working height no more than 2000m |
||||
4 |
Applicable material |
stones,grit,water,addictive, cement |
||||
5 |
Material requirement
|
1 cementing material:a:portland cement,slag cement,pozzolan 2 aggregate:a:coarse aggregate:stone-broken stone,cobblestone,broken cobblestone Maximum diameter of aggregate≤40mm b:fine aggregate:grit-natual sand, artificial sand 3. water: clean water 4.admixture: a. water-reducer b. air-entraining admixture c. pumping aid d. retarder e. accelerating agent f. early-strength admixture g. water-proofing agent h. rust inhibitor i. expander j. antifreeze |
||||
6 |
Production capacity |
10-16m3/h |
||||
7 |
The discharging height |
1m |
||||
8 |
The total motor power |
28.5kw (without the screw conveyor) |
||||
9 |
The total weight
|
7t(without the cement silo and screw conveyor) |
||||
10 |
The floor area(L*W) |
5.8m*2.3m |
||||
11 |
The mixing system |
Model number |
Motor power |
Charging capability |
The discharging capability |
|
MP500 |
18.5kw |
750L |
500L |
|||
12 |
The aggregate batching and weighing system |
The aggregate hopper volume |
The power of the electric drum |
The measuring accuracy |
||
2.4m3×2 |
3kw*2 |
±2% |
||||
|
14 |
Cement weighing system |
weighing |
The weighing hopper dimension |
The weighing accuracy |
||
Cumulative measurement |
0-150 kg |
≤±1% |
||||
17 |
Water weighing system |
Water weighing |
The motor power of the water supply pump
|
The weighing accuracy |
||
Turbine flow meter |
0.75kw |
≤±1% |
||||
18 |
weighing system |
Admixture weighing |
The mixing addictive pump power |
The weighing accuracy |
||
Turbine flow meter |
0.75kw |
≤±1% |
||||
Optional Device
NO. |
Name |
Model |
QTY |
Remark |
|
1 |
Finished products conveyor |
frame |
Steel welding |
1set |
optional |
belt |
B=800 |
1 set |
|||
Support roll |
φ89 |
|
|||
Electric drum |
4KW |
1 set |
|||
2 |
Powder hopper |
Cement silo1 |
1.4m³ |
Optional according to user requirements |
optional |
Cement silo 2 |
2.2m³ |
||||
Cement silo 3 |
3m³ |
||||
Piece type Cement silo |
SNC30t,50ton, |
||||
3 |
|
Screw conveyor |
φ168 |
|
|
Details of the plant:
1. batching hoppers:
2. mixer
Inside of the mixer
3. instrument box
4. support legs, height can be adjusted according to clients' requirement
5. Belt Conveyor
6. high pressure cleaning system
7. Mettler Toledo Sensor
Clients Visit
- Technical support online service provided.
- Technical files service provided.
- On-site training service provided.
- Spare parts replacement and repair service provided
- we provide customize service to our clients according to the requirement
Taian Shizhe Trading Company, combined with the manufacture(Shandong DOM Machinery Equipment Co., Ltd) and trading company, mainly produce and export Concrete Batching/mixing Plant, Asphalt Mixing Plant, Stabilized Soil Mixing Plant and related equipments, including cement silo, concrete mixer, batching machine, screw conveyor and so on. Besides, small road machine, tower crane and other construction machinery are also an area for research and development.
Our customers are from 43 countries all over the world. We provide customize service for our customers.
We are a young company with rapid developing speed, energetic and professional research and develop team, young and responsible sales managers. We want positive assessment from our customers and provide best quality and service.
1. Q: Where are your customers from?
A: Our Company is extending the trade scale at present. We have clients all over the world, such as Russia, Australia, Singapore, New Zealand, Canada, Malta, Turkey, Ukraine, Mongolia, Belarus, Qatar, Bangladesh, Mozambique, Brazil, Peru etc, and won the trust of the customers with good reputation. We make active effort to promoting the modernization construction of our country, encouraging the economic and technical communication with the world, and enhance the friendship with people all over the world.
2. Do you provide customize service?
Yes, we do. We can customize different products according to our customers' requirement.
3. Do you provide sample?
Yes, for most of our products, we provide sample for customers' reference. But, for the whole plant, we cannot provide. We welcome our customers to visit us very much.
4. Q: What is your MOQ?
A: Our MOQ is one set.
Thanks for your patience.
If you have any further question, please do feel free to contact.
