Technical Parameters of MP planetary concrete mixer
Model |
MP500 |
MP750 |
MP1000 |
MP1500 |
MP2000 |
Output Capacity (L) |
500 |
750 |
1000 |
1500 |
2000 |
Input Capacity (L) |
750 |
1125 |
1500 |
2250 |
3000 |
Output Mass (kg) |
1200 |
1800 |
2400 |
3600 |
4800 |
Mixing Power (kw) |
18.5 |
30 |
37 |
55 |
75 |
Discharge Power (kw) |
2.2 |
2.2 |
3 |
3 |
4 |
Scraper (nr) |
1/2 |
1/3 |
2/4 |
2/4 |
3/6 |
Side Paddle (nr) |
1 |
1 |
1 |
1 |
1 |
Discharge Paddle |
1 |
1 |
1 |
1 |
2 |
Lifting Power (kw) |
4 |
7.5 |
11 |
15 |
22 |
Skipper Capacity (L) |
870 |
1300 |
1740 |
2610 |
3480 |
Skipper Mass (kg) |
1305 |
1950 |
2610 |
3915 |
5220 |
Skipper Speed (m/s) |
0.25 |
0.25 |
0.25 |
0.25 |
0.25 |
Weight (kg) |
2000 |
3500 |
6000 |
7000 |
8500 |
Dimension (mm) |
2220x2071x1880 |
2581x2336x2195 |
2891x2602x2217 |
3223x2902x2425 |
3625x3230x2630 |
|
|
|
|
|
|
1. Drive system with motor (380V/50HZ(changing with user’s requirements)) and gearbox(designed by our own patent and with three years guarantee )
2. Mixer trough with maintaining doors, observing port,security switches, wear-resistant liners and tiles, water pipe, and water sprayer.
Vivian Chen
Mobile: +86 15853111612
E-mail: Batching1998(at)
Skype: brew.equipment
We are the manufacture since the year 1998, specially produce concrete batching machine, cement mixing station, concrete batching plant, JS series mixing machine, which can be widely used on brick machine, concrete block making machine, also we can produce equipment according to your request, mean any request can be customized in production design. Jinan JianLing Machinery Co., Ltd. is a professional supplier in construction machine, our products can be used for brickyard working the brick making machine, forklift and load carrier etc..The PL series batching machine can be connect with JS series concrete mixing machine and supply sand cement material for automatic brick machine. Also we have technology for producing the planetary mixer, spiral conveyor, screw conveyor , its material can be carbon steel and stainless steel spiral conveyor, which can widely used for hoisting the food material, or chemical material etc. It is conveniently for elevator and lift working.
Thanks very much of your inquiry, please let me know your e-mail and I can help you to know more of our company and the construction equipment in Jinan city. Jinan city is famous of kinds of machine, for example , beer brewing equipment, beer tanks, fermentation tank, pet food machine, forklift, load carrier, tower crane, Jaw crusher, stone crusher, concrete batching machine, concrete batching equipment, sand cement mixer. Cement mixing machine, spiral conveyor, etc...
Keep me in contact, thanks for your visiting and checking .!
Concrete mixing station
- 1. HLS series second-order concrete batching plant adopts biaxial horizontal double-shaft compulsory concrete mixer, with even mixing quality.
- 2. Lump-sum aggregate equipped with the same capacity of mixer, the productivity was 15% higher than the mixing plant 30%.
- 3. Aggregate, water, admixtures weighing, control, signal conversion device adopts imported components, high precision sensor, automatic control of microcomputer, each weighing or cumulative weighing, weighing precision and stable performance.
- 4. The complete machine is under computer control, making both automatic control and manual operation available.
- 5. The tower appearance looks orderly and magnificent, with main body closed with insulation board or single-layer color coated sheet, the tower inside is clean and enjoys good environment-friendly performance.
