baler twine machine prices
- 0 per Month
- QINGDAO
- T/T
Product Details
Condition: | New | Application: | Winding Yarns | Automatic Grade: | Automatic |
Production Capacity: | HIGH SPEED | Memory Capacity: | 1400rmp/min | Place of Origin: | Shandong, China |
Brand Name: | ROPENET | Model Number: | RM | Voltage: | 220v/380v |
Power(W): | 370W | Dimension(L*W*H): | 86*64*43cm | Weight: | 97KG |
Certification: | ISO9001:2008 / CE | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Final Product Picture
Machine Model
We have four model spool winder machine :
One model :2 in 1 twisting winder machine RMSL-10-T
Two model:6 head spool winder machine RMSW
Three model:2 head spool winder machine RMSL-0810
Four modle :RM0406 high speed sewing twine spool machine
One Model:RMSL-10-T 2 in 1 twisting winder machine
It is newly designed and developed for twine spool making,yarn twisting and spool making can be finished in one machine in one time.
This machine is our company’s new product high-speed twisting and winding machine.
It is a new type rope making machine that can finish stranding and winding one time.
4000twists/minutes, equipped with meter counter and frequency converter.
One person can operate 3-5 machines with high efficiency and low noise truly
Item | Technical parameter | Remarks |
Model | RMSL-10-T |
|
Model of motor | IFG-50-3-4 | Frequency converter |
Maximum power | 3KW |
|
Rated revolution | 1440r/min |
|
Rated voltage | 380V |
|
Inveter | Danfoss | Denmark |
Power of inveter | 3KW |
|
Outline dimension | 2570X1176X1742mm |
|
Size of twine | 2-5mm |
|
Weight | 900kg |
Two model:RMSW spool winder machine ,6 head ,can make 2"-8" spool
Spool winding machine:
l with length counter.
l with yarn broken auto-stop device.
l with electron tension and silicone oiling device.
l with disconnecting automatic memory function.
Model | RMSW-02 | RMSW-04 | RMSW-06 | RMSW-08 |
Size of spool | 2” | 4” | 6” | 8” |
No of Spindles | 6 | 6 | 6 | 6 |
No of Spool for each spindle | 6 | 2 | 1 | 1 |
Length of Twine | 0—500m | 0—10000m | 0—20000m | 3000-10000m |
Appearance | Cone or column | Cone or column | ||
Motor | 220V/380V,50HZ,180WX6, | 220V/380V,50HZ,250WX6 | ||
Machine Size | 2250mmX800mmX1150mm(LXWXH) | 2500mmX1000mmX1500mm | ||
Outer Carton Dimension | 2350mmX900mmX1350mm | 2600mmX1100mmX1600mm | ||
Machine Weight | 420kg | 480kg | ||
Total Weight | 550kg | 630kg |
Three model:RMSW-0810,2 head can make 8"-10" spool
Item | Technical parameter |
Model | RMSW-0810 |
Motor model | YLJ100-5 |
Max output torque of motor | 5N.M |
Rated revolution of motor | 1400r/min |
Controller model | TMA-4B |
Magnetic brake model | DZD10-0.4A |
Magnetic brake power | 6N.M |
Max diameter of expand tube | 60mm |
Mini diameter of expand tube | 50mm |
Outer dia * inner dia* height | 250mm*50mm*250mm |
Outline dimension(L*W*H) | 1635MM*1060MM*1800MM |
Machine weight | 480kg |
Four modle:RM0604 HIGH SPEED WINDING MACHINES
RM0604 high speed winder is applicable for winding sewing thread , embroidery thread , nylon
thread ,etc. This machine features availability of computer-based separate control of each single
spindle , a frequency –change slotted spool yarn guide device , an electro-magnetic tension force
control system , a pump-based cycling –type oiling device , etc. characteristics of a good shape
formation , high efficiency , easy operation , assured safety and reliability and broad applicability ,
etc.. Please don’t hesitant to contact us for more of your questions and we’ll offer the competitive
price with good quality to you!
Computer yarn-length measurement.
1. Yarn length measured by computer, accuracy +1%.
2. Yarn speed adjustable, which from 400 to 1,000 meter/per minute.
Automatic lubrications system.
1. Threads are being uniform lubricate, thanks to the constant yarn speed, the
oiling roller speed is adjustable.
2. Release the tension from beginning to the end; it makes the winded package good appearances
3. LED display easy operation.
Specification:
Model | RM0604-A | RM0604-H | RM0604-Y |
Shape | Cone type | Cylinder type | Horn type |
No of spindles | 4 | 4 | 4 |
Cone for each spindle | 1or 2 | 1or 2 | 1or 2 |
Tube angle | 0°-2°20′ | 0° | 2°20′-5°57′ |
Max. winding speed | 800mtrs/min | ||
Max. winding-up Dia. | 115mm | ||
Measurement(M^3) | 2.35*0.8*1.25 | ||
Pattern round number | 3-4 | ||
Full spool length | 0-60000m | ||
Winding linear speed | 200-1000m/min |
Company Profile
Shandong Rope Net Machinery Co.,Ltd,we are manufacturer of kinds of extruders,ring twister,twisted and braided rope making machine,rope packing machines ,winding spool machine winding ,ball machine ,shrink machines and strapping machines.
Our Team
Certificate
Question
The machines will be made as your requirements. We are appreciated if you can provide the information as follows:
1.Diameter range of product .
2.Spool weight and size
3.Spool Material
4:Country Voltage
FAQ
1. Q: How can I get the price?
A: You can contact me online or send me inquiry. Please provide the details of your requirements as clear as possible. So we can send you the price at the first time. For designing or further discussion, it is better to contact us with trade manager of alibaba, QQ, Skype, or other instant ways, in case of any delays.
2. Q: How can I get photos and videos about rope machine?
A: we can supply you all details photos of our machine. if you need, we can take operating video for you.
3. Q: Are you a factory or a trade company?
A: We are a professional rope machine factory, and we have export right.
4. Q: Can you do the design for us?
A: Yes, we have a professional team having rich experience in rope machine design and manufacturing. Just tell us your request; our engineers will try their best to get it; you can also send us your design drawing, we can make the machine follow it.
5. Q: How can I install the machine?
A: For extruder, our engineer can install it for you; for ring twister, we can install one group before delivery; for twisted rope machine, ball winder, spool winder,etc. they are finished machine, no need to install.
6. Q: Can i operate the machine easily?
A:Yes, all our machines are intelligentized, and easy to operate, anyone can operate follow the instruction
7. Q: What is your term of delivery?
A: We accept EXW, FOB, CNF, etc.
8. Q: How can I get the machine?
A: We usually deliver machine in container by ship.
