Specifications
1) Surface finish: painted, hot dipped galvanized2) OEM service provided
We are a professonal manufacturer of scaffolding,scaffolding couplers,frames and related products.
We are a leading manufacturer of system scaffoldings and accessories, couplers, shoring props, fences, ladders, frames, pipes, steel trays, and other related products in Rizhao City, Shandong, China.
We have been in the business for more than 16 years, and all our products are BS 1139 and EN 74 certified, the quality is the best. Our products are very popular in European countries, Australia, North America, Mid-east countries, and South East Asia and some African countries, etc.
RINGLOCK SCAFFOLDING
1 Breif Introduction
- Ringlock scaffolding, also called Modular Scaffolding and Multidirectional Scaffolding, the junction enables quick and easy connection of load bearing items as well as reinforcing parts to each other with an enormous rigidity.
- Ringlock scaffolding is the new generation product of cuplock sacffolding.The buckle part is a disc which diameter 133mm,and thickness 10mm. Scaffold vertical is a tube of D48*3.5mm which material is Q235/Q345B. On the vertical welded many disc every specific distance ,there is 8 holes on the disc,used to jonit the posts. On the bottom of vertical post is a base collar used to connect the scaffolding and the ground. Ledger is made by a tube with two wedge welded on the ends separately
2 Specification
Item |
Ringlock system |
Dimensions(mm) |
Weight(KG) |
Surface treatment |
WY001050 |
Vertical Φ48.3x3.25mm |
500 |
3.0 |
Hot-Dip galvanized |
WY001100 |
1000 |
5.4 |
Hot-Dip galvanized |
|
WY001150 |
1500 |
7.7 |
Hot-Dip galvanized |
|
WY001200 |
2000 |
10.0 |
Hot-Dip galvanized |
|
WY001250 |
2500 |
12.4 |
Hot-Dip galvanized |
|
WY001300 |
3000 |
14.8 |
Hot-Dip galvanized |
|
WY001400 |
4000 |
19.3 |
Hot-Dip galvanized |
|
WY002023 |
Starting Collar |
230 |
1.6 |
Hot-Dip galvanized |
WY002043 |
430 |
2.7 |
Hot-Dip galvanized |
|
WY003073 |
Ledger Φ48.3x3.25mm |
732 |
3.5 |
Hot-Dip galvanized |
WY003075 |
750 |
3.6 |
Hot-Dip galvanized |
|
WY003100 |
1000 |
4.0 |
Hot-Dip galvanized |
|
WY003106 |
1065 |
4.1 |
Hot-Dip galvanized |
|
WY003109 |
1088 |
4.6 |
Hot-Dip galvanized |
|
WY003129 |
1290 |
5.2 |
Hot-Dip galvanized |
|
WY003140 |
1400 |
5.3 |
Hot-Dip galvanized |
|
WY003150 |
1500 |
5.7 |
Hot-Dip galvanized |
|
WY003157 |
1572 |
6.4 |
Hot-Dip galvanized |
|
WY003200 |
2000 |
7.6 |
Hot-Dip galvanized |
|
WY003207 |
2072 |
8.4 |
Hot-Dip galvanized |
|
WY003250 |
2500 |
9.5 |
Hot-Dip galvanized |
|
WY003257 |
2572 |
10.0 |
Hot-Dip galvanized |
|
WY003300 |
3000 |
11.4 |
Hot-Dip galvanized |
|
WY003307 |
3072 |
11.7 |
Hot-Dip galvanized |
