Chinese Factory Expanded Metal Mesh

FOB Price

US$ 1 - 15 / Square Meter

1000 Square Meters(Min. Order)

Port Tianjin
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Brand Name	Super Star
Model Number	EMM-002	Material	Other, aluminum,steel, and other metal plates
Type	Expanded Mesh	Application	Other, Fence Mesh, concrete in building,covering screen,fencing
Hole Shape	Other, diamond	Aperture	2.54.5mm-2360mm
Wire Gauge	1-6mm

Product Description

Specifications

Expanded Metal Mesh
1.thickness: 0.04mm to 8mm
2.opening: 0.8mmx1mm to 200mmx150mm
3.quick delivery
4.good quality

Chinese Factory Expanded Metal Mesh

Expanded Metal Mesh is the most practical and economical way to assure strength, safety, and a non-skid surface. Expanded metal is ideal for use on plant runways, working platforms, and catwalks, as it is easily cut into irregular shapes and can be installed quickly by welding or bolting.

Materials of Expanded Metal
Expanded Metal can be made from aluminum,steel, nickel, titanium, brass and other metal plates, with a thickness ranging from 0.04mm to 8mm, opening ranging from 0.8mmx1mm to 200mmx150mm.

Use of Expanded Metal
Expanded Metal products are extensively used in a wide variety of industries and daily life, as gratings, laths, screens, fences, filtration media and building decoration materials.

Patterns of Expanded Metal
Expanded Metal can be processed in different opening shapes, typically as: standard rhombicshape; heavy type Tortoise-shaped expanded metal, also known as hexagonal shape; flattened; and some special shapes or designs.

Finish Treatment of Expanded Metal

Galvanized; oxidized; PVC coated; flattened; special treatment according to customers’ requirements.

Specification

Expanded Metal
Thickness	nominal size of mesh			Standard size		Weight
Thickness	SWD	LWD	Strand width	LWM	SWM	Weight
D	TL	TB	B	B	L	Kg/m2
0.5	3	6		100 200	2000	1.76
	3.2	8
	5	10
	6	12.5		1800	3000	1.08
	7	14		1800	3000
	8	16		2000	3340
	9	20		2000	3340
	10	25	1.12	1800 200	3600 4000	0.88
	12	30	1.35
0.8	10	25	1.12
	12	30	1.35			1.41
	15	40	1.68
1.0	10	25	1.12
	12	30	1.35			1.76
	15	40	1.68
1.2	10	25	1.13
	12	30	1.35			2.12
	15	40	1.68
	18	50	2.03
1.5	15	40	1.69			2.64
	18	50	2.03
	22	60	2.47
	29	80	3.25			3.53
2.0	18	50	2.03	1800 2000 2500	3600 4000 5000
	22	60	2.47
	29	80	3.26			4.42
	36	100	4.05			4.42
	44	120	4.95			5.29
3.0	36	100	4.05
	44	120	4.95
	55	150	4.99	2000	5000	4.27
	55	150	4.99	2500	6400	4.27
	65	180	4.60	2000	6400	3.33
	65	180	4.60	2500	8000	3.33
4.0	22	60	6	1500 2000	2000-3000	12.84
	30	80	4.5		2000-4000	10.46
	38	100	5		2000-4500	9.91
5.0	24	60	6		2000-3000	19.62
	35	80	6
