Key Specifications
Get Latest Price
Usage:
Chicken
Place of Origin:
Zhejiang, China
Brand Name:
EL
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Usage
Chicken
Place of Origin
Zhejiang, China
Brand Name
EL
Model Number
EIFTPC-60480
Certification
CE
Specifications
State patented technolgyEasy operate
Space saving
Highlights:
1. With state patented laminar airflow technology and narrowed temperature gradient water cooling designs, even and uniform temperature and airflow fields will be achieved, resulting in optimum chick quality and lower power consumption.
2. Space saving: holds more eggs per m2, leading to less building costs.
3. Effective cooling: air cooling, Dual water cooling systems design makes it highly adaptive to the environment.
4. Spray humidification delivers perfectly distributed humidity and makes bio-security easy.
5. Touch-screen interface: facilitates visual simplicity in operation.
6. Practical functions: fumigation & exhaust, auto timing, variant temperature group setting and temperature calibration.
7. With history data recording and analyzing function, you get useful curve diagrams.
8. History data can be output into a USB flash disk.
9. Option: Hatchery air handing system with energy-recycling technology (recycling both latent heat and sensible heat).
Main parameters:
Setter:
1. Egg capacity: 40320/80640/60480/12096 eggs
2. Apparent power: 9.9 ~ 27.6KW
3. Power supply: 380/220VAC 50Hz
4. Insulation resistance:≥2M
5. Egg turning angle: 43±2°
6. Temp control range:31.5°C∼39.00°C
7. Humidity control range: 40∼80%RH
Hatcher
1. Egg capacity: 40320eggs
2. Apparent power: 6.3 KW
3. Power supply: 380/220VAC 50Hz
4. Insulation resistance:≥2M
5. Egg turning angle: 43±2°
6. Temp control range:31.5°C∼39°C
7. Humidity control range: 40∼80%RH
Specifications:
Specification |
Size of box
(D×W×H)mm
|
Egg capacity(piece)
|
Trolley specification
(capacitytierquantity
size mm)
|
Egg tray(hatcher tray)specification
(capacitysize mm)
|
Apparent power(Kw)
|
|
Setter |
40320 |
5100×2770×2771
|
40320 |
5040158730×1290×2220
|
42316×302×75
|
9.9 |
60480 |
6980×2770×2771
|
60480 |
50401512730×1290×2220
|
42316×302×75
|
13.8 |
|
80640 |
5100×5460×2771
|
80640 |
50401516730×1290×2220
|
42316×302×75
|
19.8 |
|
120960
|
6980×5460×2771
|
120960
|
50401524730×1290×2220
|
42316×302×75
|
27.6 |
|
Hatcher |
40320 |
5100×2770×2771
|
40320 |
5040158775×1317×236
|
1681305×380×119
|
6.3 |
|
Two board types available:
1. Sandwich panel made of color paint steel plate + polystyrene foam, 74mm thickness
2. Sandwich panel made of FRP from Kemlite Co + polystyrene foam, 74mm thickness
| ||||||
