Four Wheel Tractors Definition

Four Wheel Tractors Definition thumbnail-1
Four Wheel Tractors Definition photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Guangxi Hepu County Hui Li Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Fangcheng/Qinzhou Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Certificate Other
Brand Name HuiLi
Model Number HL184
Place of Origin Guangxi, China
After-sales Service Provided No overseas service provided

Four wheel tractors definition



Cabin Big DongFeng
HL184  Wood Transport Mini Tractor dimensions Overall dimensions (LxWxH)mm 5645×2000×2800
Carriage dimension  (LxWxH)mm 3200*2000*600+400
Driving type 4x4
Wheel base (mm) 3800
Wheel track (front/rear) (mm) 1530 / 1680
Min. ground clearance (mm) 190 mm
Weight data Curb weight (kg) 3800
Rated payload(kg) 10000
Persons in cab (persons) 2
Gross vehicle weight(kg) 3800
 Wood Transport Mini Tractor main performance Max. speed(km/h) 70
Max. slope of climb(%) 25
Engine of    Wood Transport Mini Tractor   Model YN4102
Type Four-cylinder, water cooling, Four-stroke diesel engine
Displacement(L) 2.493
Rated power(kw/rpm) 33KW(2400rpm)
Horse power 95hp
Rated torque (N.m/rpm) 160Nm
Gearbox Model 5T50+131
Speed ratio 1th gear)7.48;2)4.31;3)2.45;4)1.54;5)1.00;back motion:8.19
Suspension Front suspension/Leaf spring number front 9pcs,thickness 8mm;
rear 10+7pcs,thickness 10mm
Wheels and tyre size (front and rear) 8.250-16/8.25-16
Electric device Rated voltage 24
Battery 80Ah
Basic instrument
Option






Four wheel tractors definition

Four wheel tractors definition



Four wheel tractors definitionFour wheel tractors definition
