Car Hydraulic Jack

3.Design of current overload protection

4.Design self-locking power structure and safety unloading knob, in case of the power has been disconnected,the increased jack will not fall, then when re-connecting the power, jack will go on working in accordance with instruction, or using the safety unloading knob to fall, which will effectively protect the user's personal safety

5.Fully enclosed design of the hydraulic tank, the machine used at any angles will not leak oil.

6.The machine just connects the car cigarette lighter, then the car will be risen and fallen.

7.Small, portable,easy to operate.

SPECIFICATION:

Application Method:

Jack Function:

(1)Stop the car, tension the car brake.

(2)Check the switch whether it is to the close position, it should be to “O” state, if no, please do it so first, then connect the power plug into the car cigarette lighter.

(3)Put the jack in the side of car tyre, align the loading part of automobile chassis, then rotate the adjusting screw to make it close to the automobile chassis as far as possible.

(4)Adjust the function switch to “Lift”, the direction switch to “Up”, then the jack will start to work, till the distance between the car tyre and the floor is about 5cm, reset the power switch, while the power is disconnected, the machine would lock automatically and wouldn’t fall.

(5)After changing the tyre, adjust the direction switch to “Down”, the jack would start to fall in constant speed.

(6)Finish all, please collect the cables and tools in the line winding box.

Inflation Function:

(1)Prepare for the equipment well, pull out the air hose and choose the suitable inflatable head to connect, then turn on the power.

(2)Adjust the function switch to “Inflation”, then it would start to inflate, please check the change of the pressure gauge.

(3)If finishing, please close the power first, then pull out the inflatable head to collect in the tool box. Later also pull out the plug from the cigarette lighter, then collect the cables into the tool box.

ACCESSORIES:

1. Portable Multifunctional Electric Jack   One Piece

2. Instruction Manual   One Piece

3. Guarantee Card     One Piece

4. Mini tool bag: The inflating needle,one of American-type Inflatable head, one of British-type Inflatable head, one of fuse for cigarette lighter, one of six-angle spanner

Applicable models:

Product Detail Show:

PACKING:

COLOR CARTON WITH FOAM PACKING

WARRANTY: ONE YEAR

CERTIFICATE: CE, UL, ISO9001
