2.5 Ton Material Handling Systems Shovel Loader Mini Wheel Loader
Main Technical parameters:
Overall dimension | |
Model |
ZLY925 |
Bucket capacity(m^3) |
1.1 |
Rated load mass(kg) |
2500 |
Operation mass(kg) |
5800 |
Max. Dumping height (mm) |
3000 |
Uninstall instance (mm) |
850 |
Wheel base (mm) |
2250±10 |
Wheel tread (mm) |
1500±10 |
Boom rise time (s) |
4.5 |
Dump time |
3.5 |
Boom fall times(s) |
3 |
Overall dimension (mm) |
6100X2200X3000 |
Engine model |
Weichai Brand 4105 |
Rated power/speed(kw) |
72 |
Max climbing degree(°) |
30° |
Drive type |
4WD |
Brake type |
Hydraulic disk brake |
Tyre type |
16/70-16 |
Drive axle brand |
WEIYU |
model of torque converter |
YJ280 |
torque converter pattern |
hydraulic transmission |
gearbox type |
fixed-spindle power shift |
gear shift |
2 gears ahead,2 gears astern |
Specifications
1 four-wheel-drive
2 under the whole arm
3 no increase in weld strenth
4 hydraulic brakes
5 large bucleket capacity
wheel loader performance
1 |
Engine(CHANGCHAI,WEICHAI,DONGFANGHONG,etc) |
2 |
Axle(WEIYU,HUAAN,QIAOWEI,etc) |
3 |
Bucket(snow plow,pallet fork) |
4 |
Spraying(baking finish craft or normal craft) |
5 |
Tyre(750 or 825) |
6 |
Fan or air-condition |
In terms of wheel loader shipping:
1.For the small wheel loader, such as ZLY908,ZLY912,ZLY912F,ZLY916A,ZLY918 and ZLY920,it can be put into 1 × 20' ft container,2 or 3 sets in 1x40'hq container.
2.For the 2.5T-5T wheel loader,such as ZLY925,ZLY928,ZLY936,ZLY956,1 set can be put into 1x240'hq container,2 or 3 sets in 2 × 40'hq container.
We have a large quantity stock. For stock order, the shipping time is with 7 days. For other order, the shipping time is about 7-15 days. It also depends on the order quantity.
why do you choice us ?
1. We are professional wheel loader manufacturer with 10 years experiences in China.
2. All of our wheel loaders have most high quality and competitive price.
3. Loders' colour can be yellow, red, green ect, as you like.
4. Certification: CE, ISO9001:2000 etc.
5 Delivery time: within 15 days after we hav
e received advance payment.
6. Customer first: Anytime or anywhere or any question i will reply to you as soon as possibl
Our certifications:
Trade Shows:
