Main Technical Parameters:
Specification |
Model No. |
ZLY920 |
|
Rated load |
2000KG |
|
Bucket Capacity |
1.0cbm |
|
Dump Height |
3200mm |
|
Dump distance |
900mm |
|
Wheel Base |
2300mm |
|
Wheel Tread |
1500mm |
|
Machine weight |
4300kg |
|
LxWxH (Without fork) |
5500*1800*2800mm |
Engine |
Model |
WEICHAI BRAND A52 |
|
Type |
Direct injection, water cooling, Four cylinders |
|
Rated Power |
53KW |
|
Rated Speed |
2400RPM |
Steering system |
Type |
Articulated hydraulic steering |
|
Max. turning angle |
35°± |
|
Min. turning radius |
4600mm |
Brake system |
Service braking |
DISC Brake |
Tire |
Standard tire |
20.5-16 |
|
Optional tire |
16/70-20 |
Configuration |
luxury cab with fan, radio, reverse mirror, reverse camera, Mechanic joystick, Engine preheating, cabin heater, Bucket Width 1800mm. |
|
Luxury cab with fan,radio,reverse mirror,reverse camera,adjustable steering wheel,muitlfunction dashboard,adjustable seat with safe and armrest,more comfortable operating environrment.
Adopt LED light ,long life span,more beautiful
Various optional equipments and buckets can satisfy different needs of customers.
Standard tire:20.5-16
Optional:1670-20
Fully hydraulic steering system,power shift transmtission,easier operation.
If you like this wheel loader,please contact me,I will give the best price and service.
