4WD Deisel Engine Wheel Loader With EPA Europe Standard Tiny Wheel

Shandong Tuishan Heavy Industry Machinery Co., Ltd.
4WD Deisel Engine Wheel Loader With EPA Europe Standard Tiny Wheel thumbnail-1
4WD Deisel Engine Wheel Loader With EPA Europe Standard Tiny Wheel thumbnail-2
4WD Deisel Engine Wheel Loader With EPA Europe Standard Tiny Wheel thumbnail-3
4WD Deisel Engine Wheel Loader With EPA Europe Standard Tiny Wheel photo-1
4WD Deisel Engine Wheel Loader With EPA Europe Standard Tiny Wheel photo-2
4WD Deisel Engine Wheel Loader With EPA Europe Standard Tiny Wheel photo-3
US$ 5,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Tuishan
Model Number:
ZLY916A
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name Tuishan
Model Number ZLY916A
Place of Origin Shandong, China
Type Backhoe Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 4600*1700*2500
Rated Load 1.5 ton
Certification CE ISO
Warranty 12 months
After-sales Service Provided Overseas third-party support available

                                      916A new design wheel loader with xinchai engine





                                    Model of wheel loader 916A



PerformanceOverall weight kg3800
LxWxH mm4600x1700x2500
Rated bucket  capacity mc0.7
Bucket indicatorYES
Rated load kg  1500
Dump distance 1100
Max break out force kn43 kn
Max grade ability35 degree
Dumping height2650
Dumping reach1100mm
Raising time4.5
Total cicle time11
Min turning radius 3900mm
Engine Brand Weichai  EURO 2
Model 490
Optional Xinchai 490 498 EURO3
TypeXINCHAIA4988T1
Rated power kw/cv36.8
Rated speed rpm2400
Min fuel consumption ratio9.98L /100km
Fuel tank capacity40L
Cylinder 4 cylinder EURO 3
Transmission system Model of torque converterYJ 240
Type Hydraulic transmission
Gearbox typeFixed spindle power shift
Gear shift41672
Max speed35km/h
Hydraulic systemWorking pump mpaCBGj1045,CBGq1018
System working pressure ZL20B
Oil tank capacity 39L
Steering system Type Articulated Hydraulic steering
Max turning angle27±1°
Min turning radius mm3900mm
Brake system Brake serviceDisc brake
Brake parkingSoft axle control ,outside
Tire Standard tire 20.5/70-16
Front tire pressure260KPA
Rear tire pressure265KPA
Drive axleAxle modelHub Axle
Wheel tread 1360
Wheel base 1900
Anti skid front axle  yes
Anti skid rear axle yes
DriveModel4x4

4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel 4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel4WD deisel engine wheel loader with EPA Europe standard tiny wheel
