Specifications
1.A high degree of automation2.multi-heat resource: biamass furnace, gas, oil 3.using the lowest costbatch drying unit for grain with rice husk heat resource
15T/D dryer with ultraviolet germicidal killing, our company goes through market research, independent research and development of new products. The first time in China UV-C band 253.7 nm wavelength of UV disinfection technology clever application of pesticides in the food drying process, a variety of mold in the killing of food, while the direct short-wave ultraviolet radiation interference and damage the DNA of food pests structure, restrain the proliferation of reproductive effects, that is conducive to long time storage of grain, but also to environmental protection engineering technology and organic food processing technologies together. The technology has been patent. (Patent: 200910144521.3)
Features:
1. A high degree of automation (hot air, grain temperature, moisture-line automatic monitoring, with automatic fault alarm, grain automatic cycle, the material, the system automatically shut down)
2. multi-burner (furnace with a multi-purpose systems to coal, firewood, crop stalks, chaff can be used as the heat source used)
3. using the lowest cost (per dry and 15T rice by reducing water content 5%, the coal was 115 yuan, burning rice husk was 53 dollars)
Scope: UV germicidal dryer apply insecticidal rice, corn, wheat, sesame, rapeseed, peanut, melon seeds, and beans.
| Model | JX5HM-10.0 | 5HXG-12.5 | 5HXG-15 | 5HXG-30 | ||
| Grain type and capacity | paddy(kg) | 1010-10000 | 1010-12000 | 1010-15000 | 1010-30000 | |
| Wheat(kg) | 1100-13000 | 1230-14000 | 1230-18000 | 1230-33000 | ||
| Air Fan | model | 4-72-6A | 4-72-6A | STG-6C | ||
| air flow | centrifual air fan | mix flow air fan | ||||
| dia of air output(mm) | Φ600 | Φ600 | ||||
| rotation speed(r/h) | 1450 | 1850 | ||||
| air caspaci(m3/h) | 13500 | 17500 | ||||
| Pressure(PA) | 800 | 950 | ||||
Furnace | model | gun ejection/spray | automatic temparature control | |||
| controlling form | automatic | manual | ||||
| ignition fuel | coal/diesel oil | husk | wood | straw/sticks | blind coal | |
| fuel consumption | 3.0-14L/h | 35 | 35 | 50 | 18 | |
| Total power(KW) | 5.6 | 6.4 | 7.2 | 14.4 | ||
| Exterior size(mm) | 2400*3400*7500 | 2400*3400*8850 | 2400*3400*10500 | 4460*3400*10500 | ||
| performance | material input time(min) | 40-45 | 40-45 | 45-50 | 45-50 | |
| material output time(min) | 50-55 | 50-55 | 60-65 | 60-65 | ||
| dry speed(%h) | 0.6-1.5 | 0.6-1.5 | 0.6-1.5 | 0.6-1.5 | ||
| Configurations | Over input alertor,over load protection system temparature detector,security fuse,persure sensor creepage protection,burner off-alertor | |||||
Our company is a professional manufacturer in corn and grain processing machinery for 20 years, all products have passed IS09001: 2008 international quality system certification, holding 16 new national practical patents, with self exporting rights. Our market covers over 300 sales networks in China and 40 countries such as Latin, Africa and Southeast Asia, etc.
We undertake construction of large processing projects for corn, wheat, buckwheat and other grains, design and provide total solution of complete production line with 20-2000 Tons Per day.
Main Business Scope:
1. large, medium, small dry and semi-dry corn germ extracting and coarse grain deep &fine processing machinery and turnkey projects.
Corn/maize processing: complete equipments for corn milling , germ removing, germ selection , grits (larger, medium and small size) with 20-2000 tons per day .
Deep processing of corn/maize: corn Pearl Rice, corn high gluten flour, corn dumpling flour, corn noodle flour, fine corn flour.
2. Complete equipment for old flour mill renovation and corn fine processing series with 5-2000 tons;
3. Millet & sorghum Processing Line with 5 tons -10000 tons;
And all of the single equipments series used in complete production line or seperately.
