Help Center100t/d Corn Flour Mill
Related Products
-
Fine Maize MillerNegotiableMOQ: 1 Unit -
Hot Sale Maize Flour Dry Milling PlantNegotiableMOQ: 1 Unit
-
1T/H Factory Equipments Grain Powder Milling MachineNegotiableMOQ: 1 Unit
-
Stainless Steel 80-200Mesh Animal Feed Stuff Milling MachineNegotiableMOQ: 1 Unit
-
20TPD Corn/Wheat Grinding Machine ManufacturerNegotiableMOQ: 1 Unit
Specifications
1.The line use dry milling technologies2.Simple installation, high output rate
3. most advanced technology
6FYSCT-Series of Dual (Grit, Flour) Corn Products (Dry Milling) Line
This series line includes:
6FYSCT-10 6FYSCT-20 6FYSCT-30
6FYSCT-50 6FYSCT-100 6FYSCT-200
FEATURES
1.The line adopts complete dry milling. Compared with wet milling and semidry milling, the products and sideline products do not need to be bake out, which reduces the cost of desiccation, e.g.: area, equipment, fuel, human resources etc., consequently reduce a considerable part of investment for our clients;
2.High rate of finish grade corn grits and corn flour, the fineness is adjustable in certain range, which can be flexible to meet the market demands. Creating higher value for our clients;
3.The line has simple structure, high adjustability for the field area and the workshop, no special requirements. Effectively cut down the fixed investment;
4Simple installation, fast construct progress, short construction period, allowing our client to meet the benefits in the shortest possible time;
5.The device specific, differing from the flour lines and rice lines, the core devices are all designed and invented by our company for the specific device, to make sure the product has high quality;
6.The flexible machining technics have high adaptability to the raw grains, for variously regions and quality of raw grains design corresponding process;
7.The line adopts the most advanced technology, with the logical power equip, make this product more effected and saving more energy, the core devices also obtained the Chinese National Patent. This will be the perfect choice for fine corn grits and corn flour producer;
FUNCTIONAL DESCRIPTION
Thisseries of dual corn products line build up with: corn process equipments (e.g.: corn huller, corn polisher, germ extractor, new super fine corn grits machine and adjuvant material purification etc.) and foodstuff process general equipment (e.g.: hoist, density corn de-stoner, plansifter, miller, flour cleaner). The products can be divided into variously grade corn grit, corn flour and fine feed.
The complete system line has: advanced technology, excellent equipment, strong specific usage, logical construct display, low energy cost, high yield rate, and high quality product etc.
This product is employed in food companies, starch sugar companies, and breweries.
TECHNICAL REFERENCE
TYPE |
POWER (KW) |
POWER COST/T(KW/T) |
OUTPUT (T/24H) |
SIZE REQUIREMENT (L×W×H mm) |
10t |
40 |
60-62 |
10 |
10×4×5(line construction) |
20t |
72 |
58-60 |
20 |
24×5×6(line construction)14×5×6 (steel frame construction) |
30t |
108 |
58-60 |
30 |
30×5×5(line construction) 24×5×6 (steel frame construction) |
50t |
172 |
56-58 |
50 |
35×5×7 (steel frame construction) |
100t |
346 |
56-58 |
100 |
40×7×10 (steel frame construction) |
200t |
664 |
54-56 |
200 |
50×7×10 (steel frame construction) |
