log rounding and debarking machine
Log debarker rounding
Debarker is used for log for round before peeling. And it is suitable for the eucalyptus, pine,
cotton wood . with principle of peeling, removing the log’s skin and straighting logs.
hydraulic driven feed mechanism,can quickly, efficiently put log removal of bark, round. One
set debarker can supply 2 set peeling machine .
it saves the original manual peeling, rounding procedure, save 5-6 human .
Main features:
1, increase of single and double roll’s diameter, improving the speed of remove skin .
2, single, double roll surface with chrome plating, improve wear resisting of roller.
3, the hydraulic feeding mechanism, a cutter, rapid, and feed pressure can be adjusted and
display, adapt to different wood .
4, simple operation, convenient maintenance, requirements for operators
and workers is not high technology.
4ft Log Debarker rounding YWWR-4 | |
Length of peeler log |
1400mm |
Diameter of peeler log |
500mm |
Speed |
50meters/min |
Size of the blade |
1500x140x12.7mm |
|
Total Power |
Double roller motor 7.5 kw |
Single roller motor 7.5kw | |
Hydraulic roller motor 4 kw | |
Overall size |
3560x2150x1100mm |
Weight |
About 2400KG |
8ft Log Debarker rounding YWWR-8 | |
Length of peeler log |
2600mm |
Diameter of peeler log |
500mm |
Speed |
40meters/min |
Size of the blade |
2700x180x16mm |
|
Total Power |
Double roller motor 11 kw |
Single roller motor 11 kw | |
Hydraulic roller motor 4 kw | |
Overall size |
4900x2200x1450mm |
Weight |
About 4800KG |
pls feel free to contact me
