Specifications
42mm planetary gear motor1.Voltage:24V
2.Torque:50-550kg.cm
3.electric motor dc 24v
4. with encoder ,12ppr
45mm planetary gear motor,
electric motor dc 24v
42mm planetary gear motor
12v 42mm planetary gear motor
1.Automatic curtain machines.Medical equipment,Rotary machine advertising lights
2.Voltage:6.0-24V
3.Speed:as customers' needs
4.Stall Torque: 90kg.cm
5.Low noise,low current no spark
6.Motor with encoder,16 pulse signal
7.Reduction Ratio:1/3.7-3730
8.size:45.0*140.0 mm,140 mm length mini planetary gear motor
9.We can offer the samples first ,the MOQ is 100 pieces ,and the delivery time is 20-25 days.
Gear motor Technical Data
Gearbox with motor:GMP45-775PM-2460-XXX
Reduction ratio |
4 |
19 |
51 |
100 |
139 |
189 |
264 |
369 |
516 |
720 |
Length mm |
51.5 |
51.5 |
64.5 |
64.5 |
64.5 |
74.5 |
74.5 |
74.5 |
74.5 |
74.5 |
No-load speed rpm |
1400 |
295 |
110 |
58 |
42 |
32 |
23 |
16 |
11.5 |
8.3 |
Rated speed rpm |
1125 |
235 |
88 |
45 |
32 |
24 |
18 |
14 |
10.5 |
8 |
Rated torque kg.cm |
4.5 |
12 |
27 |
54 |
75 |
93 |
100 |
100 |
100 |
100 |
|
entary tolerance torque kg.cm |
11.5 |
48 |
110 |
210 |
300 |
300 |
300 |
300 |
300 |
300 |
Gearbox with motor:GMP45-775PM-0648-XXX
Reduction ratio |
4 |
19 |
51 |
100 |
139 |
189 |
264 |
369 |
516 |
720 |
Length mm |
51.5 |
51.5 |
64.5 |
64.5 |
64.5 |
74.5 |
74.5 |
74.5 |
74.5 |
74.5 |
No-load speed rpm |
1150 |
240 |
92 |
46 |
35 |
25 |
18 |
13 |
9.3 |
6.6 |
Rated speed rpm |
900 |
190 |
71 |
36 |
26 |
19 |
14 |
11 |
8.5 |
6.0 |
Rated torque kg.cm |
2.8 |
13 |
26 |
51 |
71 |
89 |
100 |
100 |
100 |
100 |
|
entary tolerance torque kg.cm |
11 |
54 |
110 |
216 |
300 |
300 |
300 |
300 |
300 |
300 |
