tt Motor High Rpm 775 Motor and 24v dc Motor

tt Motor High Rpm 775 Motor and 24v dc Motor thumbnail-1
tt Motor High Rpm 775 Motor and 24v dc Motor thumbnail-2
tt Motor High Rpm 775 Motor and 24v dc Motor thumbnail-3
tt Motor High Rpm 775 Motor and 24v dc Motor photo-1
tt Motor High Rpm 775 Motor and 24v dc Motor photo-2
tt Motor High Rpm 775 Motor and 24v dc Motor photo-3
US$ 3.5 - 4.5 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
TT MOTOR
Model Number:
TRS-775PM
Contact Supplier Request Quote Chat Now
TT Motor (Shenzhen) Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name TT MOTOR
Model Number TRS-775PM
Usage Fan, Home Appliance, Other, Fan, Home Appliance, electric tools,automobiles
Certification ROHS
Type Other, dc motor
Torque 6500 g.cm(stall)
Construction Permanent Magnet
Commutation Brush
Protect Feature Explosion-proof
Speed(RPM) 4250-16000 rpm(no load)
Continuous Current(A) 0.26-2.7 A
Output Power 30.83 W
Voltage(V) 12V/24V
Efficiency Other, 65%

MODEL:TRS-775PM

1.Typical Applications:Printer,Copy Machine,Sewing Machine,
  Water Pump,Hair Dryer,Circular Saw,String Trimmer,etc



2.high efficiency,less noise,and low current,24v dc motor



3.can match with 45mm planetary gearbox,or 51mm gear box



4.shaft:5.0mm diamter,shaft length 14.5/19.5mm



5.mounting holes:2-M4.0x0.7



6.double shaft for encoder,12ppr



7.we can provide samples for your test.



MODEL
VOLTAGE
NO LOAD
AT MAXIMUM EFFICIENCY
STALL
OPERATING RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
OUTPUT
TORQUE
CURRENT
V
rpm
A
rpm
A
mN.m
g.cm
w
mN.m
g.cm
A
TRS-775PM
2765
6.0-30.0
24.0
7600
0.37
5810
0.22
73.53
750
44.7
312.35
3186
8.23
4045
6.0-15.0
12.0
4600
0.60
3500
4.30
84.31
860
36.6
352.94
3600
16.1
