Home > Electrical & Electronics > Electric Motor > DC Motor > 22mm Brushless Geared Motor

22mm Brushless Geared Motor

Name: 22mm Brushless Geared Motor
Brand: TT Motor
SKU: 139549581
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

TT Motor

Model Number:

GMP22-TEC2419

Contact Supplier Request Quote Chat Now

TT Motor (Shenzhen) Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Hong Kong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name TT Motor

Model Number GMP22-TEC2419

Usage Car, Home Appliance, Other, Car, Home Appliance, optical equipment

Certification ROHS

Type Other, Brushless dc motor

Torque 0.2-8kg.cm

Construction Permanent Magnet

Commutation Brushless

Protect Feature Totally Enclosed

Speed(RPM) 4.5-300rpm

Continuous Current(A) 0.15-0.18A

Output Power 1-3 W

Voltage(V) 12V 24V

Efficiency Other, 75%

Specifications

22mm brushless geared motor
1.Built-in driver
2.24.0 X 37.0mm
3.Life time: 5000-15000 hr
4.RHOS

22mm brushless geared motor

GMP22-TEC2419

Application

pump robot,lock, Auto shutter, USB fan,Slot machine,Money detector,
Coin refund devices,Currency count machine, Towel dispensers,
Automatic doors,Peritoneal machine,Automatic TV rack, optical equipment
Office equipemt ,Household appliances,Automatic

Characters

DC Brushless Motor with 24mm planetary gearbox
Voltage: 12V 24V
size:24.0 X 37.0mm, just 37mm length micro motor
Reduction Ratio: : 16,62,84,104,231,316,370,455,1014
High torque,Built-in driver
Clockwise/Counter-clockwise rotation
FGSpeed feedback signal
Over-current protection
Over-voltage protection
Under-voltage protection
Samples can be sent first ,the MOQ is 100 pieces ,and the delivery time is 15-20 days.

Parameters and dimensions of 22mm brushless geared motor

Gearbox with motor:GMP22-TEC2419-1262-XXX-12V

Reduction ratio	16	62	84	104	231	316	370	455	1014
Length mm	18.1	21.7	21.7	21.7	25.4	25.4	25.4	25.4	29
No-load speed rpm	360	100	73	58	25	18	15	13	6
Rated speed rpm	300	75	55	45	20	15	12	10	4.5
Rated torque kg.cm	0.2	0.7	1.0	1.2	2.3	3.0	3.7	4.5	8
entary tolerance torque kg.cm	0.5	1.5	2.5	3.5	7	9	9	9	9

Gearbox with motor:GMP22-TEC2419-2487-XXX-24V

Reduction ratio	16	62	84	104	231	316	370	455	1014
Length mm	18.1	21.7	21.7	21.7	25.4	25.4	25.4	25.4	29
No-load speed rpm	500	135	100	82	37	26	23	18	8
Rated speed rpm	420	100	80	65	30	22	18	15	6.9
Rated torque kg.cm	0.2	0.7	1.0	1.2	2.3	3.0	3.7	4.5	8
entary tolerance torque kg.cm	0.5	1.5	2.5	3.5	7	9	9	9	9
