12v Brushless Motor for Vacuum Pump

12v Brushless Motor for Vacuum Pump thumbnail-1
12v Brushless Motor for Vacuum Pump photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
TT motor
Model Number:
TEC3650
Contact Supplier Request Quote Chat Now
TT Motor (Shenzhen) Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name TT motor
Model Number TEC3650
Usage Boat, Car, Electric Bicycle, Fan, Home Appliance
Certification ROHS, Other
Type Micro Motor
Torque 200-290 g.cm
Construction Permanent Magnet
Commutation Brushless
Protect Feature Totally Enclosed
Speed(RPM) 4000-6500rpm
Continuous Current(A) 0.6-1A
Output Power 6.6-11w
Voltage(V) 24v
12v brushless motor for vacuum pump

Application
  • fan,automatic energy saving bath,electrical controlled valve,oxygen machine,optical equipment,Automat
  • cordless power tool,optical equipment,lighting, vacuum pump
Characters
  • size:36*50 mm , 50 mm lenth long mini brushless motor.
  • voltage:24v
  • speed:6500 or 4000 rpm
  • torque:200g.cm
  • shaft length:13.8 mm 9mm 15mm
  • Built-in driver
  • PWM Pulse wide speed range
  • Clockwise/Counter-clockwise rotation
  • FGSpeed feedback signal
  • Over-current protection
  • Over-voltage protection
  • Under-voltage protection
  • 10000H life time
  • Number of motor phase: 3
  • Can match planetary gearbox
Parameter and dimension of 12v brushless motor for vacuum pump

Type

Rated voltage

No-load speed

No-load current

Rated speed

Rated torque

Rated current

Output power

Stall  torque

Stall current

VDC

r/min

mA

r/min

g.cm

mA

W

g.cm

A

TEC3650-2465

24.0

6500

200

5400

200

1000

11

1180

2.0

TEC3650-2440

24.0

4000

120

3200

200

600

6.6

1000

2.0

TEC3650B1

6

2000

190

1400

150

600

2.17

530

2.0

TEC3650B2

12

4500

150

3500

230

880

14.21

920

2.2

TEC3650B3

24

6000

150

4300

320

760

14.21

920

2.2





12v brushless motor for vacuum pump
12v brushless motor for vacuum pump

12v brushless motor for vacuum pump

can be equipped with geabox
