LZSR series Roots blower
LZSR seaies working principle:
Roots blower is a positive displacement blower, air volume delivered is proportional to the number of revolutions, clover-type impeller rotation once every three times by two impeller suction and discharge, compared with two leaf type, gas pulsation fewer, smaller load changes , high mechanical strength, low noise and vibration is also small.
LZSR series Roots blower Characteristics and tectonic:
1.low noise. Fan intake and exhaust ports with a spiral structure, the intake and exhaust fan rotate with the rotor gradually , to avoid the ripple and noise due to the old fans turn on and off instantly generated , so running balance , low noise. Products supporting the muffler uses advanced sound-absorbing materials and special structures , but also effectively reduce the fan noise .
2. running balance , no vibration . The adoption of advanced machining center dedicated impeller machining the rotor backlash uniform, and the formation of an equilibrium state , on this basis , balancing the rotor through more sophisticated experiments , the fan running almost no vibration.
3. High efficiency and low energy consumption. Using a specially designed fan rotor meshing of advanced composite curve line , sealed, leak less , volumetric efficiency is further improved.
4.long life . 20CrMnTi fan gear used by carburizing treatment , grinding, precision five tooth surface more resistant. Bearing with large carrying capacity double roller bearings . Thus increasing the life of the fan .
5.Output air clean. Fan with a special mechanism designed to avoid the oils into the chassis , so the air does not contain any oil output .
6.standardized production . All fans including accessories products are designed and produced to achieve standardization , interchangeability and versatility, to meet high-quality, low-cost, high-volume production purposes.
7. Selection convenient and reasonable. Product specification models , sub-file finer performance parameters is more intensive. Therefore, to facilitate customer choice , lower cost is good enough .
LZSR Series main parameters:
Fan diameter : 50-350A
Air volume : 0.44-180m ³ / min
Pressure : 9.8-98 kgf / cm²
Motor power : 0.75-560kw
Standard accessories:
Universal Dock
Belt cover
Fan pulley, the motor pulley, V-belt
Suction silencer (with air filter)
Safety valve
Pressure gauge
Lubricating oil
Stone bolt
1)Each model has a performance tables and standard, easy to select fan model
2)Including accessories, fan theme implement standardized production. A sound production system, can always meet your needs.
3)Because a good helix, using the same blower and silent air filter with a matching muffler operating noise of the fan are much lower than in the past.
4)The rotor is fully machined precision products produced during processing has made a complete balancing, almost no vibration.
5)Take small design, installation area.
THREE LOBES ROOTS BLOWER PHOTOS:
