High frequence 2g 3g 5g 6g ozone medical air purifier

Specifications

High frequence ozone medical air purifier
1.high purity ozone therapy machine
2.feed oxygen source
3.high output

High frequence ozone medical air purifier
-------Model NO.: NT-ZTW

 Descripiton:

Specification:

Item	Oxygen flow rate	Ozone output	Power	Output gas tube	Fuse	Size	NW
Model	LPM	G/Hr	W	mm	A	mm	Kg
NT-ZTW 2G	1-3	2	90	φ6	3	360×370×150	8.2
NT-ZTW 3G	1-3	3	100				8.3
NT-ZTW 5G	2-5	5	120				8.4
NT-ZTW 6G	2-5	6	130				8.5





















Noted:

1. Above ozone capacity were tested under oxygen source

2. Net weight will be 10% different for different plug.



Features:
1. Corona Discharge technology

2. Built in Domestic Patent-Ceramic ozone tube with electric board

3. Feed outside oxygen source only with high ozone concentration

4. Ozone adjustable range: 20%-100%

5. Digital Timer : one or two recycle working time

6. Stylish, small size, plug& play

7. Changeable plug for different country.

8. Output : 2G/Hr, 3G/Hr, 5G/Hr, 6G/Hr.

9. Suitable used for the line which required high ozone concentration

Control panel:

 Flow meter, Ozone adjuster, Oxygen input, Ozone output,

Ampmeter, Switch, Timer, Working light, Power light



How to use ?



1.Before use this machine,put it in a stable flat place which can hold its weight.

2.Use the power equipped with the machine;

3.The machine use for air purification,fisrtly attach the silicone tube into the ozone

outlet and then turn on the power;

4.Set the timer and then come out ozone, and put the tube into the room.

5.When use for room air purification, it requires nobody is present, after 30 minutes

people can walk into the room.

6.If use for water treatment, the air stone should be attached into the silicone tube and

put into the water.

7.Attention, the machine should be placed higher than the water, in case that the water refluex occur.





Applications:

Laboratory:

>>Chemical oxidation for raw material of flavors and fragrances,small water treatment experiment



Pharmaceutical industry:

>>Water,air conditioner, workshop, dressing room, sterile room etc



Medical:

>>Ward,operating room, medical devices, sterile room etc



 High frequence ozone medical air purifier

♦In the way of removing Formaldehyde,the difference between ozone and

activated carbon:



 The activated carbon has to be put still indoor when using

it to adsorb the formaldehyde.

The air flows slowly indoor which causes the activated carbon adsorbs the harmful

material in a limited space.And it also need to change the filter screen regularly.

If not,it will release harmful material on the contrary.

On the other hand,ozone is gas.

The room can be filled with ozone completely without blind angle.

Then ozone resolve the formaldehyde.

Also ozone is widely recognized as the most efficent bactericide in the world.

Hospitals have already replaced UV lamp with ozone generator.



♦Is ozone harmful to human body ?



 Once the ozone concentration fails to meet the hygiene and safety standard,

we can notice with our sense of smell and dodge away or take actions to avoid

further leakage.

So far there is no one dealth reported caused by ozone poisoning.



♦Does the ozone generator work efficently ?



 Undeniably,ozone can sterilize and remove odor and formaldehyde.

It is reported that ozone is a widely used bactericide.It can kill escherichia coli,

bacimethrin efficently and resolve the harmful material in a short time.







Quality control:

• Every procedure has personnel inspection.
• All the products must be tested and qualified before packaging.
