Bar Line Displacement Sensor/Laser Distance Sensor/Small Magnetic Sensor

We offer one of the largest variety of Linear Draw Wire Sensors in measuring ranges from 100mm up to 100000mm. A variety of configurations are available, providing alternative features. A number of outputs are available, including Poteniometer, Voltage, Current,and Quadrature Encoder.

KTM_300mm Distance Measuring Sensor and Linear Senor,Displacement Sensor

Pictures for your reference:

1. Principle

Draw-wire displacement sensor measures linear movements using a highly flexible steel cable. The cable drum is attached to a sensor element which provides a proportional output signal.

2. Features

1. rugged construction, compact size, easy to install

2. economic cost, and cost savings for customers

3. cylinders, testing machines and other industry has achieved large-scale applicatIons, reliability

3. Displacement sensor Advantage

Key Features

• 0 to 5000mm measuring range
• Rugged, compact design
• Profiled enclosure
• Analog wire sensor
• Protected to IP67
• CE Approved

Note:

Wrong wiring may damage the sensor

Make sure wire in the power off state

Do not let go after wire is pulled out, otherwise the sensor could be easily damaged

Do not exceed the total length of the wire

Please ensure the cleanness of the equipment and wire line to prolong the service life

Avoid external force

welcome your inquiry ! glad to serve you and  provide suited sensors or

 displacement transducers for you !!
