Specifications
1.it is flat die model2.we have different model ,make different size pellet
pelletizing machine
wood processing product for pelletizing machine
The raw material for this pelletizing machine can be the food grain like corn, wheat and the crushed waste from agriculture for
example, corn straw, groundnut shell, grass, wheat bran,rice husk, sawdust, and animal manure and so on, they can
be pressed into both feedstuffs for many kinds of animals and biomass fuel, the diameter of the pellet can be
2.5-12 mm, when processing ,the lower temperature can maintain the nutrition of the products. And through general
extrusion, it can kill micro-organisms, parasites to prevent disease and to store it easily.
Working Principle:
Series of pelletizing machine is a machine based on circular movements, motor-driven, driven pulley to the spindle and the flat transmission mode, under the influence of the friction,
pressure roller rotation, the pressure roller and laminated create friction between the temperature, powder material
by high temperature gelatinization and protein coagulation degeneration, in the squeeze roller, the discharge from the
die hole, through the adjustment of the cutter can be the required length of particles in the feed tray will be made by
the rejection of particles by the discharge port discharge.
MODEL NO. |
OUTPUT (kg/h) |
POWER (HP or KW) |
SIZE (cm) |
NW/GW (kg) |
JL-150A |
100-150 |
8-12HP |
870×440×700 |
180/220 |
JL-150B |
100-120 |
4KW |
750X350X650 |
95/115 |
JL-200A |
250-350 |
15hp |
118*56*95 |
280/310 |
JL-200B |
200-300 |
7.5kw/380V |
100*43*95 |
200/230 |
JL-200C |
200-300 |
7.5kw/380V |
100*46*90 |
200/230 |
JL-230A |
350-500 |
22hp |
118*56*95 |
280/310 |
JL-230B |
350-450 |
11kw/380V |
114*47*97 |
290/320 |
JL-230C |
350-450 |
11kw/380V |
114*54*93 |
290/320 |
JL-260A |
300-500 |
30hp |
184*70*116 |
450/480 |
JL-260B |
400-600 |
15kw/380V |
120*52*107 |
330/360 |
JL-260C |
400-600 |
15kw/380V |
122*53*107 |
330/360 |
JL-300A |
600-850 |
55hp |
200*60*123 |
520/560 |
JL-300B |
700-800 |
22kw/380V |
127*52*107 |
410/450 |
JL-300C |
700-800 |
22kw/380V |
128*58*105 |
410/450 |
JL-360A |
700-950 |
55hp |
227*62*126 |
600/620 |
JL-360C |
700-950 |
22hp/380V |
134*58*106 |
470/500 |
JL-400A |
800-1100 |
55hp |
227*62*126 |
750/780 |
JL-400C |
800-1100 |
30kw/380V |
145*62*115 |
630/660 |
If you interest our pelletizing machine ,please contact me :
JUNLAN MACHINE
Contact :Ms Susan
Tel:0086-371-86085677
Mobile:0086-18637188608
Skype:junlanmachine168
