Subject: silos, sheet silos, steel silos, cement silo, assembled silo, bolted-type silo, powder silo, concrete batching plant silo, high quality silo, competitive price silo, 50T-2000T silo, fly ash silo. high quality cement silo, grain storage silo,cement silo
Product introduction
Used for: Luwei bolted-type cement silo is used for storing bulk materials such as grains, cement, powder, lime, gypsum, fly ash, different binder materials, gravel, limestone, sand and different chippings.
Application: Luwei bolted-type silo is mainly used in many areas, such as construction material, chemical engineering, energy resources, environmental protection and foodstuff, like loading and unloading plants, dosing-weighing and mixing plants, batching plant etc.
Product features
1) Various capacity and customized silo. The capacity of bolted-type silo ranges from 50T to 2000T flexible. All the data of silos is calculated by TJU (Tongji University), it considers strength of silo, resistance coefficient of the typhoon and bending resistance coefficient, high quality cement silo.
Technical index (just for reference):
Serial number |
Model and size |
Diameter (mm) |
Number of layers |
Leg distance (mm) |
Theoretical capacity (M3) |
1 |
PG50T |
3100 |
3 |
2027 |
40.73 |
2 |
PG60T |
3100 |
4 |
2027 |
52.21 |
3 |
PG100T |
3100/3200 |
7 |
2027/2080 |
86.64 |
4 |
PG150T |
3300/3800 |
8/6 |
2180/2570 |
111.89/115.11 |
5 |
PG200T |
4500 |
6 |
3010 |
164.5 |
6 |
PG300T |
5000 |
7 |
3290 |
235.16 |
7 |
PG400T |
5700 |
8 |
2640 |
348.62 |
8 |
PG500T |
6500 |
8 |
3015 |
458.99 |
9 |
PG800T |
8000 |
8 |
3660 |
637.63 |
2) Fully equipped factory. With mature special cutting and drilling technology, all parts are specially cleaned on the surface, and then well painted both inside and outside.
3) Professional packing and loading. All parts of silo can be packing into bundles with short loading time and little space. Whatever large size of silo, it can be shipped into container by sea all over the world.
The container require for transportation (for reference):
Type |
One set |
Two sets |
Three sets |
Four sets |
50T |
40’GP |
40’HQ |
1*40’HQ +1*20’GP |
2*40’HQ |
60T |
40’GP |
40’HQ |
1*40’HQ +1*20’GP |
2*40’HQ |
100T |
40’GP |
40’HQ |
1*40’HQ +1*20’GP |
2*40’HQ |
150T |
40’HQ |
40’HQ |
1*40’HQ +1*20’GP |
2*40’HQ |
200T |
40’HQ |
1*40’HQ +1*20’GP |
2*40’HQ +1*20’GP |
3*40’HQ |
300T |
1*40’HQ+1*20’GP |
2*40’HQ |
3*40’HQ |
4*40’HQ |
400T |
2*40’HQ |
3*40’HQ |
4*40’HQ |
5*40’HQ |
500T |
2*40’HQ |
3*40’HQ |
4*40’HQ +1*20’GP |
6*40’HQ |
4) Easy assembly. All the parts of silo can be well assembled with the help of English Installation Instruction Program. The construction will be safe and efficient.
Silo installation schedule (for reference):
5) Unique sealing technology. Luwei bolted-type silo has triple reliable seal protection.
6) Recycling use. Luwei bolted type silo is convenient to install and remove. It realizes to recycle on different construction sites and long-term service life. Also the cost for secondary investment can be reduced as well as the delivery time can be shorted.
Silo accessories introduction
Luwei can provide silo accessories together with silo, such as screw conveyor, arch breaker device, butterfly valve, relief valve, level indicator, dust filter etc.
Luwei company is a professional manufacturer in producing bolted-type silo, which has it own national patent certificate for ‘Bolted-type Powder Silos’ (Patent No.201020649684.5). It covers an area of 8000 square meter which integrates research, development, manufacture and sales into a whole. It can supply 100 sets of silos every month. The annual sales value reaches five million dollars.
Luwei bolted-type silo is used for storing bulk materials such as cement, powder, lime, gypsum, fly ash, different binder materials, gravel, limestone, sand and different chippings. Luwei bolted-type silo is mainly used in many areas, such as construction material, chemical engineering, energy resources, environmental protection and foodstuff, like loading and unloading plants, dosing-weighing and mixing plants, batching plant etc.
