car washer hydro spray 360 degree z-boom single
1.Pressure:300bar
2.Temperature:275bar/120°C
3.Material: stainless steel 304
4.inlet:G1/4"F(or on request)
5.outlet:G1/4"M swivel(or on request )
6.Ceiling boom swivelling 360°, wall boom swivelling by 180°
7.Maintenance-free ball bearing swivels
8.Optionally available counter plate
Stainless steel construction designed with two separate booms and two entrance points so that one line can be high pressure and one low pressure, or 2 high pressure if desired. One mounting plate means ease of assembly.
Booms include swivels and boom hoses. Sold in sets of 2 booms, one is 6" shorter than the other. Inlet is 3/8" FPT. Rated to 2200 PSI and 200° F.
| Connector | Length | Pressure | Temprature | Rotation angle |
| 1/4BSP F-1/4BSP M | 1600-63" | max 21MPa/3100 psi | max 120C/250F | 360° |
| 1/4BSP F-1/4BSP M | 1750-69" | max 21MPa/3100 psi | max 120C/250F | 360° |
| 1/4BSP F-1/4BSP M | 1750-69" | max 21MPa/3100 psi | max 120C/250F | 360° |
| 1/4BSP F-1/4BSP M | 2000-79" | max 21MPa/3100 psi | max 120C/250F | 360° |
| 1/4BSP F-3/8BSP M | 1600-63" | max 21MPa/3100 psi | max 120C/250F | 360° |
| 1/4BSP F-3/8BSP M | 1750-69" | max 21MPa/3100 psi | max 120C/250F | 360° |
| 1/4BSP F-3/8BSP M | 1750-69" | max 21MPa/3100 psi | max 120C/250F | 360° |
| 1/4BSP F-3/8BSP M | 2000-79" | max 21MPa/3100 psi | max 120C/250F | 360° |
Swivel connection: greasing is not necessary
Tip:3/8"M or 1/4"M connection for high pressure hose with O-Ring
