Specifications
corn flakes packaging machine1. high capacity
2.lower power consumption
3.widely useful
4. lower investment
2014 on sale breakfast cereal corn flakes packaging machine
corn flakes production machine
corn flakes production machine composition
Raw material mixer→Twin screw extruder→Shaking cooler→Air conveyor→Presser→Three layers oven→Material distributor→Air heater→Sugar sprayer→Dryer→Cooler
Technical Parameter
Model |
Installed Power |
Power Consumption |
Throughput |
Dimension |
KL65-IIIA Twin Screw Processing Line |
130KW |
90KW |
120-150kg/h |
28x1.2x2.0m |
KL85-II Twin Screw Processing Line |
180kw |
140KW |
300-400kg/h |
30x1.5x2.0m |
General introduction for corn flakes production machine
This processing line is very easy to handle.From mixing,puffing,cutting and shaping,drying,and flavoring. You can take wheat flour,corn flour,rice powder,and other cereals as raw material,which can be mixing with water in the mixer.
Mixing: put the raw materials in the mixing machine, add amount of water according to the proporty of materials.and wait for one minnute.
Extruding: the theory of extruder is using high temperature and high pressure to puffing the materials.when the extrudate out the extruder, the high pressure and temperature transform to ordinary pressure and temperature.So the water will evaporate quickly meanwhile, the textile of food is changed.
Cutting and shaping: the cutting and shaping stand after the extruder, the extrudate comes out from extruder to the cutting and shaping machine, you can change the length by adjusting the cutting speed. The shorter the food, the quicker the speed. meanwhile, by changing a shaping die,we can change another shape. our company can offer many kinds of shapes to meet you demand.
Drying: after shaping, we need a dryer to cook the food. one reason is to lengthen the life of food, another is to make food more crispy. we normally set the temperature 160'C-180'C.
Flavoring: our company using rolling methods to seasoning. the flavoring materials can be powder or liquid. meanwhile, there is a oil spraying machine with the seasoner.
Some machine pictures
Manufacturing standard
All the parts whether we purchase from our suppliers or made by ourselves must be tested according to strict standard. Each machine in our factory has to be tested and proved before its delivery.
Packing and shipping
The machines will be packed into wooden cases or wrapped by plastic film. Firstly, anti-rust oil painted to the machine, then wrapping film and air bubble pad then export non-fumigation wooden cases packing outside. Containers will be sent to our factory to load the machines and will be sealed before being sent out to make sure the safety of our machines.
Our Service
1.OEM & ODM
2.one year guarantee and life-time maintenance service.
3.Consultation service before, during, and after sales.
4.Project planning and design services.
5.Debugging of machines until all are functional.
6.Training the customers how to operate and maintain the machines correctly.
7.Offer new product techniques and recipes timely.
Our main machines catalogue
Automatic instant noodle processing line
Automatic Biscuit processing line
Bread crumb processing line,
Core filled snack food processing line,
Corn curl(kurkure) processing line
Cereal corn flakes processing line,
Fruit and vegetable chips processing line
Potato chips, stick processing line
Re-produced rice processing line
Protein food processing line
Series of packing machine
Sala , bugles crispy processing line
Sip-model corn chips processing line
Screw, shell food processing line
Nutrition grain powder processing line
Snack processing line
If you are interested, please don’t hesitated to contact us! We’ll be very pleased to help!
