small scale potato chips production line
This production line can process fresh potatoes to slice cutted chips, french fries and other various shapes of chips.
This production line consists of machinery for the receipt, washing and peeling of raw potatoes, as well as for the slicing, sorting, blanching, frying, cooling and packaging of french fries. In addition, a production line also contains equipment for transportation between operations, water and sewage management, supporting structures, service platforms and the processing of waste.
Parameter
Goods |
Specifications |
|
Washing and peeling machine |
Power: 1.1kw Size:m1.4×1.0×1.0 Weight of machine: 200Kg |
|
Work table |
Power: 1.1kw Size:m1.8×0.8×0.8 Weight of machine: 100Kg |
|
Conveyer |
Power: 0.37kw Size:m2.0×0.4×21.0 Weight of machine: 180Kg |
|
Cutter |
Power: 1.5kw Size:m0.9×0.7×1.0 Weight of machine: 300Kg |
|
Washing |
Power: 0.8kw Size:m2.8×0.8×1.2 Weight of machine: 300Kg |
|
Blanching |
Power: 1.2kw Size:m5.4×1.0×1.45 Weight of machine: 750Kg |
|
Fryer |
Power: 0.37kW+0.55kW Size:m4.35×1.0×1.6 Weight of machine: 700Kg |
|
Heating changer |
Area: 25 Sq.m. Size:m 1.0×1.0×1.2 Weight of machine: 1000Kg |
|
Waste remove machine |
Size:m 0.9×0.5×1.0 Weight of machine: 100Kg |
|
Deoil system |
Power: 0.2kw |
|
Conveyer |
Power: 0.55kw Size:m3.0×0.6×1.2 Weight of machine: 300Kg |
|
Oil tank |
Volume: 1.0CBM Size:m1.2×3.0 Weight of machine: 200Kg Including the steam heating tube and valve |
|
Flavoring machine |
Power: 0.37kW+250W Size:m1.75×1.2×1.5 Weight of machine: 300Kg |
|
Electric control box |
Size:m0.8×0.6×2.0 |
|
Pipepumpvalve |
One set |
|
Total : | ||
Steam boiler |
150,000 kilocalorie medium oil oven 0.2T/0.3MP Boiler |
|
1.0 T/1.6MP steam boiler | ||
Manufacturing standard
All the parts whether we purchase from our suppliers or made by ourselves must be tested according to strict standard.
Each machine in our factory has to be tested and proved before its delivery.
Packing and shipping
The machines will be packed into wooden cases or wrapped by plastic film. Firstly, anti-rust oil painted to the
machine, then wrapping film and air bubble pad then export non-fumigation wooden cases packing outside.
Containers will be sent to our factory to load the machines and will be sealed before being sent out to make sure the safety of our machines.
Our Service
1.OEM & ODM
2.one year guarantee and life-time maintenance service.
3.Consultation service before, during, and after sales.
4.Project planning and design services.
5.Debugging of machines until all are functional.
6.Training the customers how to operate and maintain the machines correctly.
7.Offer the customers new product techniques and recipes timely.
Our factory
If you are interested, please don’t hesitated to contact us! We’ll be very pleased to help!
