CE approval recycling cable making equipment
- 100 Set / Sets per Month
- Qingdao Shanghai Guangzhou Yiwu Urumchi Erenhot etc
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Henan, China | Brand Name: | ALLANCE | Model Number: | ALCWP -918A |
Usage: | Stripping |
Packaging Details
generally plywood case
Product Description
recycling cable making equipment
Introduction: recycling cable making equipment
This wire stripper is one of popular copper recycling machines, used to strip the plastic wrappings and metal
cores of wires apart. For the wire diameter and wire material is different, there are different wire stripping models. You can choose according to your need. The wire stripper is ideal for stripping copper wires, high-voltage cables,
sheet cable wires and cable wires ranging from 1.5mm to 90mm in diameter.
Features:
- Simple structure, easy operation
- Cover little floor space
- Labor-saving, high efficiency
Attentions:
- Snip off the cable joints when feed materials to protect the blade
- Maintain the machine at regular time
- Don't make the stripping machine overload, or it will influence the parts' service life
Basic Parts:
1. Entry capstan: it can deliver wires and strip out the wire heads
2. Wire wheel: it is used to deliver wires and strip out the wire ends
3. Entry capstan gap adjusting knob: it can adjust the entry capstan gap according to the wire size
4. Entry capstan pressure adjusting knob: it can adjust the entry capstan pressure according to the wire skin strength
5. Entry capstan uplift knob: when the wire stripping machine begins to thread wires, turn the knob to uplift the
entry capstan, so the wires can go through; when the machine runs, turn the knob to put down the entry capstan and press the wires
6. Wire wheel gap adjusting knob: it can adjust the wire wheel gap according to the wire size
7. Wire wheel pressure adjusting knob: it can adjust the wire wheel pressure according to the wire skin strength
8. Wire wheel uplift knob: turn the knob to uplift the wire wheel before taking out the wires; when the wire stripping machine works, turn the knob to put down the wire wheel
9. Tool head assembly: it is used to cut off the wires, strip wire heads and ends. The up blade and under blade
should open to the largest state under the machine halt state, so the wires can pass through tool smoothly
Technical Parameters: recycling cable making equipment
Model No. | 918-A | 918-F | KA | KOB | 918-B |
Dia. of Wire Processed | 1-25mm | 1-30mm | 1-35mm | 1-42mm | 2-90mm |
Cutting Speed | 30m/minute | 30m/minute | 30m/minute | 30m/minute | N/A |
Voltage | 220v/380v | 220v/380v | 220v/380v | 220v/380v | 220v/380v |
Power | 1.5kw | 1.5kw | 2.2kw | 2.2kw | 3kw/4kw |
Dimensions (cm) | 55*51*84 | 56*55*84 | 60*58*84 | 70*61*84 | 80*58*120 |
Weight | 60kg | 70kg | 80kg | 110kg | 200kg |
Productivity (kg/10H) | 100-300 | 150-300 | 400-1000 | 600-1500 | 800-2000 |
Packing below: recycling cable making equipment
