Top Quality CE Industrial Large Capacity Wood Chipper Machine With Factory Price

Name: Top Quality CE Industrial Large Capacity Wood Chipper Machine With Factory Price
Brand: LYWF
SKU: 139456085

US$ 2,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Wood Chipper

Use:

chipping wood

Liyang Weifeng Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Wood Chipper

Use chipping wood

Power Type Electric

Production Capacity 20tph

Place of Origin Jiangsu, China

Brand Name LYWF

Model Number BX

Dimension(L*W*H) 2.2x2.15x1.5M

Weight 3-7t

Certification CE

Warranty 1-3YEARS

After-sales Service Provided Overseas service center available

New Wood Chipper
Technical parameters Model	BX216	BX218	BX218D	BX218-11	BX2110A	BX2110B
Diameter of cutters' roller MM	650	800	800	800	1000	1000
Feeding size(HXW) MM	180X500	225X680	240X750	240X1050	330X750	330X850
Quantity of fly-cutters PCS	2	2	2	3X2	2	2X2
Speed of cutters' roller RPM	590	650	650	650	550	550
Feeding speed M/MIN	37	38	38	39	37	37
Max diameter of logs MM	120	160	160	for board	170	185
Capacity M³/H	10	22	38	30	55	62
Chips size MM	30	30	30	20	33	33
Main motor power KW	55	110	132	160	160	185
Feeding roller power KW	3X2	4X2	4X2	5.5X2	7.5X2	7.5X2
Pump power KW	Manual pump	0.55	0.55	0.55	2.2	2.2




Technical parameters Model	BX2110	BX2113A	BX2113B	BX2113-11	BX2113-13	BX2116
Diameter of cutters' roller MM	1000	1300	1300	1300	1300	1600
Feeding size(HXW) MM	330X1050	400X700	400X850	400X1050	400X1250	600X1250
Quantity of fly-cutters PCS	2X2	3	3X2	3X2	4X2	4X2
Speed of cutters' roller RPM	550	420	420	442	340	350
Feeding speed M/MIN	37	38	38	43	42	42
Max diameter of logs MM	200	230	240	250	250	310
Capacity M³/H	77	64	78	108	126	180
Chips size MM	33	30	30	32	32	30
Main motor power KW	220-250	200-250	250	315	450	710(10KV)
Feeding roller power KW	7.5X2	7.5X2	7.5X2	11X2	15X2	18.5X2
Pump power KW	2.2	3	2.2	2.2	3	4
