1t/h biomass fuel pellet machinery with gear drive and low price:
1) Ring die and gear drive type;
2) wood pellet machine without conditioner;
3) Ring die pellet mill is far superior to flat die technology;
4) Gear drive is much better than belt drive;
5) Includes one ring die and a set of rolls.
A large selection of stainless steel or alloy steel dies for this machine that can be purchased separately
1 Driven with heavy-duty gearbox construction can produce continuously in most adverse condition.
2 The imported key elements are of high performance with long life and low maintenance cost.
3 The key parts are made of alloy steel to be very strong and malleable. Die is made of stainless steel.
4 Pellet machine is widely used in the granulation of wood, straw, rice husk and other biomass sources.
Technical Parameter:
NO |
NAME |
Model |
||||
MZLH30 |
MZLH35 |
MZLH40 |
MZLH42 |
MZLH508 |
||
1 |
Capacity (wood pellet ) |
0.1-0.3 |
0.3-0.5 |
0.5-0.8 |
0.8-1.5 |
1.5-2.0 |
2 |
Power |
37 |
55 |
70/90 |
110 |
132/160 |
3 |
Screw feeder Power |
0.55 |
0.55 |
0.75 |
0.75 |
0.75 |
4 |
Pellet size |
φ6, φ8 |
φ6, φ8 |
φ6, φ8,φ10 |
φ6, φ8,φ10,φ12 |
φ6, φ8,φ10,φ12 |
5 |
No. of press roll |
2 |
2 |
2 |
2 |
2 |
6 |
Outer diameter of press roll |
146 |
165 |
190 |
206 |
222 |
7 |
Mashing rae(%) |
≤12% |
≤12% |
≤12% |
≤12% |
≤12% |
8 |
Dimension(mm) |
2006*800*1300 |
2165*895*1450 |
2302*970*2105 |
3150*1100*1650 |
3200*1300*1850 |
9 |
Weight(t) |
2.1 |
2.5 |
2.8 |
3.1 |
3.5 |
Raw material:
Remarks: We have used many biomass materials to make pellets, such as bagasse, sawdust, rice husk, red bean, all kinds of wood, eucalyptus barks.....Our technical engineers can design the most suitable compression ratio according to your raw materials.
Details picture of the machine:
Operation Photos:
Final Pellet:
Delivery domestic:
Abroad:
Welcome to visit our factory!
