High efficient pulse bag wood dust collector, dust collector system
- 20 Set / Sets per Month
- Shanghai or other ports
- T/T Credit Card
- Best selling oil mist collection centrifugal oil mist collector for CNC machines
- Ventilation cleaning equipment, negative pressure cyclone dust collector
- LIVTER Factory High Power Wood Dust Collector Industrial Dust Sawdust Collector Engraving Machine Dust
- LIVTER Dust Collector Bag Industrial Woodworking Dust Collector Cyclone
- LIVTER Cyclone Dust Separator With Filter Bag Dust Collector Woodworking Wood Dust Collector
- LIVTER Industrial Cyclone Cartridge Dust Collector For Woodworking Machine
Product Details
Condition: | New | Type: | ESP Dust Collector | Efficiency: | 99% |
Minimum Particle Size: | 200mg/Nm3 | Place of Origin: | Jiangsu, China | Brand Name: | LYWF |
Model Number: | Bag dust collector | Dimension(L*W*H): | 13668*3598*7550mm | Weight: | 5300-12400kg |
Certification: | CE | Warranty: | 1-2years | After-sales Service Provided: | Overseas service center available |
Product Description
High efficient pulse bag wood dust collector, dust collector system
Products Introduction
baghouses (also called pulse jet baghouse, pulsejet dust collectors, etc...) are self contained, fully automated where needed. We also supply and install ducting, access platforms, ventilation and instrumentation. Baghouses are engineered for dusts of 3 microns and larger, in the following applications:
- Woodworking
- Cement production
- Powder processing
- Steel melting
- Material handling
- Primary metals, including steel-making
- Metals fabrication: grinding, sawing, sanding, polishing
- Papermaking
- Mixing and blending options
- Mining
- Foundries
- Glass Plants
- Battery Plants
- Universities
We offer a full range of collector designs and media choices to solve the toughest pollution control problems involving high temperatures, pressures and corrosives.
Technical Parameters
Model | Weight(kg) | Filtering area(m2) | Dimension(mm) | Air volume m3/h |
HCMC-1.5x32 | 1264 | 20.352 | 1626x1277x4176 | 1831.68 |
HCMC-1.5x50 | 1678 | 31.8 | 1986x1457x3776 | 2862 |
HCMC-1.5x72 | 1972 | 45.792 | 2346x1687x4171 | 4121.28 |
HCMC-1.5x98 | 2233 | 62.328 | 2706x1917x4171 | 5609.52 |
HCMC-1.5x128 | 2456 | 81.408 | 3066x2117x4171 | 7326.72 |
HCMC-1.5x162 | 3466 | 103.032 | 3516x2297x4671 | 9272.88 |
HCMC-1.5x200 | 3598 | 127.2 | 3876x2477x4671 | 11448 |
HCMC-1.5x242 | 4527 | 153.912 | 4427x2677x4751 | 13852.08 |
HCMC-1.5x288 | 5016 | 183.168 | 4787x2907x4971 | 16485.12 |
HCMC-1.5x338 | 5414 | 214.968 | 5147x3147x5271 | 19347.12 |
HCMC-2.5x98 | 2489 | 103.88 | 2706x1917x5171 | 9349 |
(It's only for your reference, detailed dust collector will be designed according to your condition, so if you're interested, please do not hesitate to contact me. )
Our Service
Products Photos
Bag dust collector, dust collector machine, dust collecting machine / equipment, dust removal, dust collector price, dust collection, dust filtration equipment
