Big Flow Industrial Cyclone Filter Dust Collector
Big Flow Industrial Cyclone Filter Dust Collector Description:
A class of cyclone dust extractor is a dust removal device.Dust removal mechanism is made dust airflow rotating movement, dust particles from the air by means of centrifugal force to separate and trap in the wall, and then with the help of gravity that dust fell into ash hopper.Cyclone parts have a certain size proportion, changes in the proportion of every relationship, can affect the efficiency and pressure loss of cyclone, the diameter of the filter, the size of the air intake, exhaust pipe diameter as the main influencing factors.When use, should be paid attention to when more than one line, the favorable factors can also be converted into disadvantage.In addition, some factors favorable to improve the efficiency of dust removal, but it will increase the pressure loss, thus adjustment must take into account of various factors.
Big Flow Industrial Cyclone Filter Dust Collector Features:
1. Small equipment structure, less covers, low cost, and resistance;
2. It can be used for high temperature dust gas purification, general carbon steel manufacturing cyclone separator can be used for 100 ℃ flue gas purification.
3. Dry ash removal,it is helpful to recovervaluable dust;
4. It is widely applicable, dust collector in laying wear-resisting, corrosion resistant lining, can be used to dust in the flue gas purification with high corrosion.
Technical performance |
Model |
|||||
PMD-24 |
PMD-32 |
PMD-42 |
PMD-63 |
PMD-72 |
PMD-84 |
|
The total squire/m2 |
24 |
32 |
42 |
63 |
72 |
84 |
The filtering speed/m.min-1 |
1.04~1.67 |
1.15~1.75 |
1.21~1.74 |
1.25~1.67 |
1.27~1.62 |
1.27~1.68 |
Wind treatment consumption/m3.h-1 |
1500~2044 |
2500~3500 |
3500~5000 |
4700~6300 |
5500~7000 |
6500`8500 |
Number/piece |
32 |
48 |
64 |
80 |
96 |
112 |
Consumption/m3. min-1 |
0.032 |
0.048 |
0.064 |
0.08 |
0.096 |
0.11 |
Entrance concentration/g.m-3 |
≤100 |
|||||
Export concentration/g.m-3 |
<50 |
|||||
Plus press/M pa |
0.5~0.7 |
|||||
withstand negative/pa |
5000 |
|||||
Resistance |
≤1200 |
|||||
Welcome to chat with me about details
Liyang Weifeng Equipment Co.,LTDdd: No.2 Jianye Rd,Tianmu Lake Industrial Zone,Liyang Tel: +86 519 88308030
Mobile: Tracy: +86 15151953518(Whatsapp/Wechat)
Ms Zhou: +86 13338795677(General manager)
Fax: +86 519 88308600
Skype:lywfsb
TradeManager: cn1000552890
Website:
