YDS Series Liquid Nitrogen Container With Racks Dewar Vessle, With ISO CE Confirmed

YDS Series Liquid Nitrogen Container With Racks Dewar Vessle, With ISO CE Confirmed thumbnail-1
YDS Series Liquid Nitrogen Container With Racks Dewar Vessle, With ISO CE Confirmed photo-1
US$ 135 - 180 MOQ: 1 Set
Key Specifications
Get Latest Price
Properties:
The Basis of Surgical Instruments
Type:
Other, cryogenic container
Brand Name:
JX
Contact Supplier Request Quote Chat Now
Xinxiang Jinxin Import And Export Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai Ningbo Qingdao Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Properties The Basis of Surgical Instruments
Type Other, cryogenic container
Brand Name JX
Model Number YDS-6
Place of Origin Henan, China

 Introduction

This series liquid nitrogen containers, small size, light weight, is the field of life science experiments indispensable laboratory equipment. To ensure long-term storage of samples does not rot.



Main Features



1. A special anti-rust high strengthen aluminum alloy stretch forming production, light weight and resistant,

2. Less weld appearance after anti-rust paint cryogenic treatment,

3. Solid and reliable, long service life,

4. Mezzanine high vacuum multi-layer super insulation structure,

5. Stainless steel canister with goblets

6. Small daily static liquid nitrogen steam loss amount, liquid nitrogen static long Time saved.



Tutorial liquid nitrogen container



Users purchase a new nitrogen tank container filling of liquid nitrogen in the first, first filling some of the liquid nitrogen so that the inner container is approaching a low temperature, and then slowly filled. This also reduces the vessel suddenly touching low thermal expansion and contraction of the fission will occur inside and outside the bile container crack, resulting in shortening the life of the vessel.

In addition to the container during use gently



Application



1. Scientific experiments, analysis equipment, electronic equipment supporting.

2. Mechanical cooling assembly, material handling and other low temperature modification.

3. Save and turnover low temperature test samples.

4. Rare virus vaccine cold storage transport turnover.

5. The preservation of biological specimens livestock industry types such as storage of semen, embryos and save Marek vaccine.

6. Nano experiments.

7. Low temperature phase change thermal storage nanofluids viscosity characteristics and other supporting experimental study.

8. Restaurant food cryopreservation.

9. Health sector, life science and other active stem cell preservation genetic material







Technical Parameters:



Model:YDS-10

Capacity:10L

Diameter of Neck: 50mm

Daily evaporation rate: 0.10L/d

Static holding time: 101D

Weight full: 14.1Kg

Weight empty: 6Kg

External diameter:305mm

Total height: 530mm

Height of canister: 120mm

Number of canister: 6 pc

Max capacity of straws: 0.25ml:1788/0.5ml:792







Model:YDS-10B

Capacity:10L

Diameter of Neck: 50mm

Daily evaporation rate: 0.15L/d

Static holding time: 65D

Weight full: 14.3Kg

Weight empty: 6.2Kg

External diameter:305mm

Total height: 530mm

Height of canister: 120mm

Number of canister: 6 pc

Max capacity of straws: 0.25ml:1788/0.5ml:792



Accessories



  • Rack with vial- boxes
  • Protective jacket
  • Canister
  • Level rod
  • Roller base







We can also supply the related accessories such as all the kinds of canisters, liquid nitrogen level alarm, liquid nitrogen cart, transfer pump, protective jacket, lockable device, container racks and level measure meters.







Packaging & Shipping

Packaging Details:  Corrugated Case in pallet



If you have any special requests, please let us know and we shall meet your requirements to the best of our ability.



Delivery Detail: If have any stock, we will ship within 3days.



Our Services

  1. We offer 2years warranty, if any quality problems, we change you for a new one!
  2. Our online service is 7*24 hours!
  3. Customized the color, cap type. And stamping are accepted.Every tank will be tested before the delivery.
  4. On time delivery and satisfied sales service.

Best quality, lowest price, welcome to our factory.





Company Information

About Us



JINXIN MACHINERY CO.,LTD has more than 30 years experience in the design and manufacture of cryogenic containers and JINXIN Chemical Equipment Co., Ltd, since 1978 engaged in manufacturing of biological liquid nitrogen

container. In the 1970s, to meet the demand of scientific research, medicine and stock breeding, the company successfully developed and manufactured biological liquid nitrogen containers.





Workshop of Company
