pp plastic crusher Feature:
1. Machine looks nice, color coordination, paint firm.
2. The hopper, crushing chamber, the separation sieve bucket design, loading and unloading easy.
3. Buffer feed and import Chuilian room design, to avoid splashing materials.
4.Crushing chamber anterior and posterior wall with double glazed, low noise.
5. It has a shield belt, safe and reliable.
6. It has a clean Insurance button.
7. Motor fitted with overload protection devices and power supply chain protection system.
8. Imported high quality tool steel, special cutting tools, in particular, durable, flexible adjustment of the tool installation design can be used several times after blunt grinding,repeated use, Long life.
9. Processing technology matures, box, knife and other important parts of the overall process used to ensure the fitting accuracy.3. Knife cut seat for the cascade design, the cutting force decomposition, resulting in cutting force doubled.
10. Reasonable structure, easy operation, energy saving and durable, practical and economic.
11. universal plastic crusher, sealed bearings, the bearing rotation for a long time to maintain a good knife design is reasonable, uniform granule products, knife blocks thermal processing, design nice shape.
Technical parameters of plastic shredders
Model |
SF-III- 180 |
SF-III- 230 |
SF-III- 300 |
SF-III- 400 |
SF-III- 500 |
SF-III- 600 |
SF-III- 800 |
|
Power |
kw |
2.2 |
4.0 |
5.5 |
7.5 |
11 |
15 |
22 |
HF |
3.0 |
5.0 |
7.5 |
10.0 |
15 |
20 |
30 |
|
|
Spindle speed (r/min) |
720 |
720 |
570 |
570 |
510 |
510 |
510 |
|
|
Blade diameter (mm) |
65 |
65 |
75 |
75 |
90 |
110 |
120 |
|
Spinning blade |
6 |
9 |
12 |
15 |
18 |
20 |
24 |
|
Fixed blade |
2 |
2 |
2 |
2 |
2 |
4 |
4 |
|
Output(kg/h) |
110-200 |
150-350 |
250-450 |
400-650 |
600-850 |
800-1050 |
1000-1300 |
|
Feeding port (mm) |
180*150 |
230*200 |
300*230 |
400*270 |
500*320 |
600*340 |
800*480 |
|
Fineness |
8 |
8 |
10 |
12 |
14 |
14 |
14 |
|
Weight (kg) |
160 |
300 |
370 |
500 |
650 |
920 |
2000 |
|
The crusher is applicable to the crushing of polyethylene, nylon, project plastic, scraps and inferiors of expanded polyvinyl materials or ejection nozzle, etc. If there are corresponding sieve pores, the clearance of the knife could be adjusted. It could also crushes each kind of blow molding membrance, rolling membrance, slices, sheet and other plastic waste material.
This pp plastic crusher used to crush all kinds of solid materials which are something difficult to deal with, plastic containers, plastic buckets, plastic films, fibers and papers.
