Automatic towels packaging machine with CE

Specifications

Pillow packing machine
1. full-automatic packing machine
2. easy to operate
3. Double transducer control

 Automatic pillow type packaging machine with CE

1.Suitable for packaging soft, strip and unorganized objects like towels, tissues, noodles, egg rolls,



sausages, fish, ice-lollipop, soft candies, biscuits, fresh fruits, etc.



Features



1. Double transducer control, flexible bag length cutting, operator needn't to



   adjust the unloading working, saving time and saving films.



2. Human-machine operation, convenient and quick parameter setting.



3. Self diagnosis failure function, clear failure display.



4. High sensitivity optical electric color mark tracking and digital input cut posi-



   tion which makes the sealing and cutting more accurate.



5. Separate PID control to temperature, suitable for various packing materials.



6. Stopping the machine in selected position, no sticking to the knife and no



   wste packing film.







Model	AMSGQ-250B	AMSGQX-250D
Film width	Max. 250mm	Max. 250mm
Bag making length	65-190 or 120-330mm	65-190 or 120-330mm
Bag making width	50-100mm	50-100mm
Production height	Max. 40mm	Max. 60mm
Packing speed	40-230bag/min	40-230bag/min
Film roll diameter	Max. 320mm	Max. 320mm
Power specification	2.8Kw/220V, 50/60Hz	2.8Kw/220V, 50/60Hz
Outside dimension	4020×720×1320mm	4020×720×1320mm
Gross weight	650kg	650kg
