Home > Products > feed processing machine > Doulble Conditioner Feed Mill for fish feed, shrimp feed / Fish Feed Mill Line
Doulble Conditioner Feed Mill for fish feed, shrimp feed / Fish Feed Mill Line
- 25 Set / Sets per Month
- shanghai
- T/T Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | TOP |
Model Number: | TP350 | Type: | Feed Pellet Machine | Voltage: | 380V/220V |
Power(W): | 1.5KW | Dimension(L*W*H): | 2200x900 x1500 | Weight: | 1280 kg |
Certification: | CE,ISO | Warranty: | 3 YEARS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.low consumption,good price2.high quality,better service
3.easy to use
4.to making wood fuel pellet
5.CE,ISO
1.instruction
1.The key component is made of wheat straw pellet press machine is high quality alloy steel and wear-resisting material, using German vacuum furnace heat treatment, the service life lengthens 5-7 times .
2.it is widely used in biomass energy unit and breeding feed factory and brewing ,sugar, cigarette paper, pharmaceutical industries ,such as organic waste and granulation .
3.it widely used in grain feed and straw sawdust pellet fuel .
it is with mechanical circular motion as the foundation, power as a driving force, the motor drive, the pressure rod rotation, pressure rod and particles produced between temperature and powder material by high temperature pasting in the pressure rod under the action of the extrusion die from the vent,the left tray made of particles will be sent outside, through the cutting knife grain can be adjusted .
2. Technical Paramete
Model | TP320 | TP350 | TP400 | TP420 | TP508 | TP558 |
Capacity | 0.2--0.4t/h | 0.4--0.6t/h | 0.5--1.2t/h | 0.8--1.4t/h | 1.5--2.0t/h | 2.5-3.0t/h |
Main Power | 37 kw | 55 kw | 75 kw | 110 kw | 132 kw | 160 kw |
Force feeder power | 1.1 kw | 1.1 kw | 1.5 kw | 1.5 kw | 1.5 kw | 1.5 kw |
Feeder power | 0.75 kw | 1.1 kw | 1.1 kw | 1.5 kw | 1.5 kw | 1.5 kw |
Die Diameter | φ320mm | φ350mm | φ400mm | φ420mm | φ508mm | φ558mm |
Dimension(mm) | 2100x800 x1300 | 2200x900 x1500 | 2300x1000 X1700 | 3200x1100 x1700 | 3200x1300 x1900 | 3500x1500 x2800 |
pellets size(mm) | φ6.0,φ8.0,φ10.0,φ12.0 |
3. Photos
Contact Us
- Jiangyin Top International Trade Co., Ltd.
- Contact nameEmmet Qian
- Phone86-510-86163344
- AddressFloor 2, Office Bldg., Neighborhood Committee, Phase 1, Puhuiyuan, Jiangyin
