Best price linseed oil milling machine
AZSD-80 Oil Press Machine Introduction:
AZSD-80 oil press is a popular type of screw oil press machine, mainly composed of feeder, gearbox, pressing chamber and oil receiver.
1.Our screw Oil Press can be used in peanut ,soybean, sunflower, vegetable seeds, coconut, olive ,etc and all kinds of plants for edible oil.
2.The oil press can hot pressing and cold pressing .
3.This Oil Press is matched with one controlling cabinet box for controlling all working of the machines.
AZSD-80 Oil Press Machine Features:
1. Made of high quality steel, wear-resistant and easy to clean.
2. With the properly designed pressing chamber, the increased pressure in the chamber highly improves working efficiency.
3. It can squeeze 20 kinds of oil crops, such as, peanuts, sesame, vegetable seeds, soybean, oil sunflower, flax, etc.
4. Alloy steel is treated by carburization for improving its surface hardness and wear resistance.
AZSD-80 oil press Machine Advantages:
1.High oil yield: the oil output is 35% - 50% higher than common oil press.
2.Little land occupancy: only 10-20 square metre is enough.
3.Low noise, less pollution, quite environmental.
4.Low residual: the oil residual in cake is only about 5% .
5. Saving labor and covering small land.
The Semi-automatic Screw Oil Press Specification and Technical Data:
Model |
Power (KW) |
Capacity (Ton/Day) |
Packaging Size(mm) |
Weight(KG) |
AZSD-68 |
5.5 |
1 ~1.5 |
900*530*760 |
160 |
AZSD-68C |
5.5 |
1 |
880*480*660 |
150 |
AZSD-80 |
5.5 |
2~3 |
1810*560*735 |
370 |
AZSD-95-1 |
7.5 |
3~5 |
1910*610*765 |
480 |
AZSD-100 |
7.5 |
3~5 |
1910*610*765 |
480 |
AZSD-120 |
11 |
4~7 |
2060*610*760 |
650 |
AZSD-120C |
15 |
6~8 |
2100*700*770 |
650 |
AZSD-130 |
18.5 |
9~12 |
2280*700*770 |
850 |
AZSD-160 |
22 |
15~20 |
22800*700*770 |
1050 |
Images Of AZSD Series Oil Press:
Spare parts of AZSD-80 oil press Machine :
Our group:
If you have more questions of this machine,please contact me!
