Animals Feed Mill Introduction
This series Pellet Mill adopts mature technology to make high quality animal feed pellets for chicken, cattle, horse, duck etc with large-scale production. Based on the outstanding features of its high throughput, low consumption and mature technology, ring die feed pellet mill has become more and more popular and possess broad market share at home and aboard. It is an ideal equipment for animal and poultry breeding in grain feed factory, livestock farm, poultry farm, individual farmers, feed processing industry, etc.
Animals Feed Mill Main Structure
This series Feed Pellet Mill mainly consists of feeding device, hardening and tempering device, conditioner device, press chamber transmission system, overload protection and electric control system.
Animals Feed Mill Technical Parameter
Model |
SZLH320 |
SZLH350 |
SZLH400 |
SZLH420 |
SZLH508 |
|
1 |
Capacity |
2-5T/H |
1.5-8T/H |
2-10T/H |
3-12T/H |
4-20T/H |
2 |
Main motor power |
37KW |
55KW |
75/90KW |
110KW |
132/160KW |
3 |
Feeder power |
0.55KW |
0.75KW |
0.75KW |
1.5KW |
1.5KW |
4 |
Conditioner power |
2.2KW |
2.2KW |
2.2KW |
5.5KW |
7.5KW |
5 |
ID of ring die |
320mm |
350mm |
400mm |
420mm |
508mm |
6 |
Speed of ring die |
305RPM |
336RPM |
307RPM |
287RPM |
287RPM |
7 |
Speed of feeder |
12-120RPM |
||||
8 |
Speed of conditioner |
350RPM |
||||
9 |
Pellets size |
Diameter 2,3,4,4.5,5,6,8,10mm |
||||
10 |
QTY of rollers |
2 |
||||
11 |
OD of roller shell |
140mm |
165mm |
190mm |
206mm |
/ |
12 |
Pellets formation rate: |
≥95% |
||||
13 |
Pulverization rate |
≤12% |
||||
14 |
Stability in water |
≥20MIN |
||||
15 |
Noise |
≤86dB(A) |
≤90dB(A) |
|||
16 |
Mould temperature |
≤85°C |
||||
17 |
Pressure of steam |
0.1-0.4Mpa |
||||
18 |
Steam consumption |
≥0.3t/h |
≥0.3t/h |
≥0.4t/h |
≥0.5t/h |
≥1t/h |
19 |
Steam temperature |
130-150°C |
||||
Our Feed Pellet Machine Superiorities
* Widely used equipments with mature technology.
*Driven by high precision gear transmission system which ensures high productivity(about 20% higher than belt transmission) and low energy consumption.
* Using imported world famous bearings & advanced oil seal technology to get better transmission performance, stable operation and less noise.
*Feeding device adopts frequency conversion speed regulating motor to guarantee the particles quality.
*Multiple aperture ring die for choice, excellent craft of ring die with long service life to make smooth and high quality aquatic feed pellets.
*The international advanced compensation type spring coupling device is of novel and compact structure, safety, reliable, and low failure rate.
*Overload protection and electrical control system to ensure normal operation.
*Extra large conditioner and jacket conditioner can be chosen to meet clients’ special requirements to enhance particles tempering and hardening effects.
*Compared with flat die pellet mill, ring die pellet mill is more efficient and suitable for large scale production of animal feed pellets.
Animal Feed Pellets Raw Materials Required
The materials can be corn, maize, wheat bran, rice, beans, leftover etc.
Tips & Warnings For Our Esteemed Users
1. Take the relevant factors as a comprehensive consideration including: demand, capacity, cost, raw materials, etc while purchasing a pellet mill.
2. Right operation and maintenance is the key to extend the service life of pellet mills, so proper maintenance and repair must be carried out to achieve high product output, low consumption and increasing corporate profits.
3. It’s significant to choose right materials used in pellet production line because different material has different characteristic, surely their pellet features will be different.
Feed Pellet Machine Photos
Final Pellets Sample
Feed Pellet Line Customer Site Photos
Delivery Photos
To know more, please contact Enoch. Cell:0086-15138475697
Skype:enoch-lv
