Best Design Ring Die Cattle Feed Pellet Machine
Ring Die Cattle Feed Pellet Machine Introduction:
1.This series Feed Pellet Mill adopts mature technology to make high quality animal feed pellets for chicken, cattle, horse, duck etc with large-scale production.
2.Based on the outstanding features of its high throughput, low consumption and mature technology, ring die feed pellet mill has become more and more popular and possess broad market share at home and aboard.
3.It is an ideal equipment for animal and poultry breeding in grain feed factory, livestock farm, poultry farm, individual farmers, feed processing industry, etc.
Ring Die Cattle Feed Pellet Machine Main Structure:
This series Feed Pellet Mill mainly consists of feeding device, hardening and tempering device, conditioner device, press chamber transmission system, overload protection and electric control system.
Ring Die Cattle Feed Pellet Machine Main Technical Data:
Model |
SZLH320 |
SZLH350 |
SZLH400 |
SZLH420 |
SZLH508 |
Capacity |
2-5T/H |
1.5-8T/H |
2-10T/H |
3-12T/H |
4-20T/H |
Main motor power(kw) |
37 |
55 |
75/90 |
110 |
132/160 |
Feeder power(kw) |
0.55 |
0.75 |
0.75 |
1.5 |
1.5 |
Conditioner power(kw) |
2.2 |
2.2 |
2.2 |
5.5 |
7.5 |
ID of ring die(mm) |
320 |
350 |
400 |
420 |
508 |
Speed of ring die |
305RPM |
336RPM |
307RPM |
287RPM |
287RPM |
Speed of feeder |
12-120RPM |
||||
OD of roller shell(mm) |
140 |
165 |
190 |
206 |
/ |
Noise |
≤86dB(A) |
≤90dB(A) |
|||
Pellets diameter: 2mm, 2.5mm, 3mm, 4mm, 4.5mm, 5mm, 6mm, 8mm, 10mm
Pellets shaping rate: ≥ 95%
Pellets stability in water: ≥20Min
Roller working temperature: ≤85°C
Steam working pressure: 0.1-0.4Mpa
Steam temperature: 130-150°C
High Quality Durable Spare Parts Photos
Our Feed Pellet Mill Superiorities
1.Widely used equipments with mature technology.
2.Driven by high precision gear transmission system which ensures high productivity(about 20% higher than belt transmission) and low energy consumption.
3.Using imported world famous bearings & advanced oil seal technology to get better transmission performance, stable operation and less noise.
4.Feeding device adopts frequency conversion speed regulating motor to guarantee the particles quality.
5.Multiple aperture ring die for choice, excellent craft of ring die with long service life to make smooth and high quality aquatic feed pellets.
6.The international advanced compensation type spring coupling device is of novel and compact structure, safety, reliable, and low failure rate.
7.Overload protection and electrical control system to ensure normal operation.
8.Extra large conditioner and jacket conditioner can be chosen to meet clients’ special requirements to enhance particles tempering and hardening effects.
9.Compared with flat die pellet mill, ring die pellet mill is more efficient and suitable for large scale production of animal feed pellets.
Animal Feed Pellets Raw Materials Required
The materials can be corn, maize, wheat bran, rice, beans, leftover etc.
Feed Pellet Machine Photos
Finished Feed Pellets
Feed Pellet Production Line Customer Site Photos
Delivery Photos
To know more, pls contact Enoch.Cell:0086-15138475697
