Smart x ray baggage scanner with best price
Smart x ray baggage scanner with best price
Features
- The machine would alarm with sound and light signal when detecting specific objects;
- Web connecting, multi-ports detecting object at same time;
- Fold rotating LED display, humanity image surveillance;
- Directly touchable controlling panel without keyboard or workbench,, save space;
- Safety reliable one-button on/off operation;
- Real-time enlarge image for convenient surveillance and identify;
- Auto diagnosis system, display with fault code for maintenance.
Basic Parameters
Tunnel size |
800(W)*650(H) mm |
Speed of the belt |
0.22m/s |
Rated load of the belt |
200Kg |
resolving power |
Diameter is 0.0787mm of the metal line |
Space resolution |
level: OD1.3mm vertical: OD1.0mm |
Through resolution |
OD0.511mm |
Penetration ability |
steel plate’s thick is 34mm |
Film safety |
ISO1600 film is safe |
Leak dose |
<0.1µGy/h |
X-ray generator
Beam direction |
light from top |
Tube current |
0.4~1.2mA (adjustable) |
Tube voltage |
100--160 KV (adjustable) |
spread Angle of the ray beam |
80° |
Cooling/work cycle |
Sealed oil bath /100% |
Image processing system
X ray sensor |
L photoelectric diode array detector(multi energy), 12bit depth |
Display |
High resolution 17 "LCD display |
Color image display |
According to the material is qualitative, 24 bits true color display |
Edge enhancement |
The object contour edge clearer |
Super image enhancement |
Image detail more clearly |
High penetration show |
Improve the image of the bright contrast, make easy penetration area more clearly |
Low penetration display |
Improve the image contrast of the dark area, make the difficult penetrated area more clearly |
Magnifier |
Local amplification function, real-time dynamic amplification |
Brightening/ darkening |
Increase the brightness of the image/ Reduce the brightness of the image
|
Image back to pull |
Before the show and image, and the image can be any image processing |
Image restoration |
Image display restore the original state |
Image storage |
Real-time save any image, and can be arbitrary image processing, continuous work save |
Multi energy color |
Organic display for orange, Inorganic display for blue, Mixture display for the green |
High energy/Low energy |
Two kinds of energy switch display |
Drug and explosive auxiliary detection |
Some of the more typical auxiliary detection of drugs and explosives and other dangerous articles |
Use environment
System temperature/humidity : 0°C~45°C/20%~95% (No condensation)
Storage temperature/humidity : -20°C~60°C/20%~95% (No condensation)
System voltage : 220VAC(±10%) 50±3HZ
Power loss : 1.2KW(max)
Noise level : <58dB
Smart x ray baggage scanner with best price
Smart x ray baggage scanner with best price
Wooden case packing with seal belt.
