500ml Lab Research Equipment Full Closeness Ultrasonic Reactor TOPT-1000D
US$ 3,000 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Type:
Other, Ultrasonic pulverizer
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
60L Top Quality Mechanical Industrial Ultrasonic Cleaner Of TP-1000TUS$ 2,100 - 2,900MOQ: 1 Set -
60L Top Quality Mechanical Industrial Ultrasonic Cleaner Machine With Big TankUS$ 500 - 3,000MOQ: 1 Set
-
Easy Operation Low Temperature Ultra High Pressure Continuous Flow Cell Crusher 3500 Bar / 50750 Psi With Digital DisplayUS$ 50,000 - 150,000MOQ: 1 Set
-
New Generation Ultrasonic Wave Stainless Steel Digital Commercial Ultrasonic CleanerUS$ 232 - 262MOQ: 1 Unit
-
High Quality Sonic Reactor Low Temperature Ultra High Pressure Continuous Flow Cell Crusher for SaleUS$ 50,000 - 150,000MOQ: 1 Set
Condition
New
Automatic Grade
Automatic
Type
Other, Ultrasonic pulverizer
Place of Origin
Shaanxi, China
Brand Name
TOPTION
Model Number
TOPT-1000D
Voltage
220V
Power(W)
1000W
Dimension(L*W*H)
500mm*500mm*2000mm ~ 3500mm*3500mm*8000mm
Weight
25kg
Certification
CE,ISO
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
TOPT-1000D Full Closeness Ultrasonic Reactor
produced according to your needs.
1~5L, standard openings
Description of Full Closeness Ultrasonic Reactor TOPT-1000D
Closeness reactor of ultrasonicProduct Description
TOPT-1000D-type ultrasonic reactor temperature closed for sound chemical reaction, enzymatic reaction, nano-materials preparation, animal and plant cells, viruses, cell fragmentation, emulsification, smoothing, emulsion breaking, dehydration, separation, extraction, digestion and reduction, anti-foaming, oil desulfurization, refractory organic wastewater treatment, oil sludge cleaning off the oil, the remaining biological sludge dewatering, algae, algal, and sterilization, cleaning and so on. Also widely used in chemical engineering, materials engineering, environmental engineering, biochemistry, microbiology, pharmaceutical chemistry, surface chemistry, physics, zoology and other fields
Ultrasonic generator has two main categories:
One is ultrasonic wave generated by mechanical methods, there are pneumatic (air whistle) and the hydraulic type (liquid whistle); another is the use of mechanical and electrical effect in the ultrasonic: ultrasonic cleaning machine with reactor, immersed in response to sound horn device and the cup reactor.
Acoustic horn shaped reactor is immersed in high-power ultrasonic transducer horn immersed in the liquid reaction, the large amount of energy directly to the reaction medium, an effective electrical energy into mechanical energy to make, and can be changed transported to the amplitude of ultrasonic probe size control of ultrasonic energy, laboratory extraction and chemical reactions commonly used in such equipment.
Sound horn immersion reactor has the advantage of sound intensity adjustable, get a higher intensity, disadvantage is difficult to control the temperature of reaction liquid, the probe surface by the cavitation corrosion reaction of the liquid may cause pollution.
Key Features
1. The whole closed structure, can access a variety of gases involved in reactions
2. Immersion ultrasonic horn, good effect
3. Ultrasonic power continuously adjustable, maximum power 50 ~ 1000W adjustable
4. Ultrasonic pulses individually switch, pulse excitation time is adjustable, pulse count of the number of automatic control
5. Ultrasonic transducer and liquid contact parts can be used titanium, corrosion-resistant
6. Double jacket glass reactor, 50 ~ 500mL reactor to choose
7. Jacketed reactor volume, can pass into the cold water or oil bath, and achieve precise temperature control
8. Display and temperature control with temperature sensing devices can be directly immersed in the reaction system
9. Reactor can be connected to a reflux condenser, dropping funnel feeding, import gas bubble, vacuum exhaust and other chemical synthesis device accessories, chemical synthesis reactor suite of trace organic synthesis kit optional
10. Ultrasonic horn and reactors dedicated seal adapters, supporting various parts of the casing sealed into the reactor, the reaction is completely closed
11. Super magnetic stirring, to fully mix the sample
The Full Closeness Ultrasonic Reactor packaging
Our services
Customized product is also welcome TOPTION, thank you !
