Specifications
1.Volume: 1L~150L
2.Reacting tem:-80~300
3. GG17, SS, PTFE sealing
4. University brands designated
5. Explosion-proof device
high pressure laboratory chemical reactor TOPTION
Theory and Application of Mini High Pressure Reactor
1. Make cumbersome experimental simple, it can be realized in one operation with different environments
or with different environment temperature/ pressure diversified series of different experiments.
2. Through the RS232 communication interface a computer connected to print and show the historical value
and the actual curve according to user’s needs, the whole system can be monitored real time by software.
Technical Parameter of labortary electric heating reactor
|
Mini high-pressure reactor with magnetic stir
|
TOPT–MC0.025/10 |
1.Volume:25ml 2.Design pressure: <10MPa 3.RT--200°C,with magnetic stir 4.Material:stainless steel SS304 |
TOPT-MC0.05/10 |
1.Volume:50ml 2.Design pressure: <10MPa 3.RT--200°C,with magnetic stir 4.Material:stainless SS304 |
|
TOPT-MC0.1/10 |
1.Volume:100ml 2.Design pressure: <10MPa 3.RT--200°C,with magnetic stir 4.Material:stainless SS304 |
|
TOPT-MC0.2/10 |
1.Volume:200ml 2.Design pressure: <10MPa 3.RT--200°C,with magnetic stir 4.Material:stainless steel SS304 |
Description of high pressure reactors:
Material: The type of stainless steel high pressure reactor which mainly adopt 1Cr18Ni9Ti, made of quartz glass two materials, special requirements may be lined treatment, improving the ability of strong corrosion resistant material.
Mechanical and connection configuration: Connection structure using bolt structure or fast start snap ring connection, quick-opening effort, but can improve the kettle lid, kettle body can be removed.
Mixing method: stainless steel high pressure reactor using magnetic cylindrical rotary coupling structure, stirring speed of 0 ~ 1000r / min, and users need to be adjusted to mixing capacity.
Security: The reactor is equipped with safety valve, the safety valve adopts diaphragm valve blasting, blasting numerical error is small, and the instantaneous exhaust gas speed is fast, safe and reliable. Each reactor valve with needle valve, reciprocating closed form, the seal is reliable and durable, all types of valve mounting reasonable, discharge flow, no dead corners.
Heating method: Using electric heating. Also providing electric heating, liquid heating type, electrical, hydraulic dual heated according to customer requirements.
Control system: Equipped with intelligent control device ,the control device uses intelligent digital control instruments, providing the motor speed, reaction temperature and pressure inside the vessel and other data acquisition and control, with high precision, easy operation, strong anti-interference ability and other characteristics.
Application of high pressure reactor
Therefore, the reactor is more suitable for a variety of flammable, explosive, highly toxic, precious media and chemical media of strong penetration to stir. It is the best no-leak response equipment for petroleum, chemical, organic synthesis, polymer materials, food and other process to Vulcanize, Fluorite, and Oxidize.
Product of high pressure reactors
