FSFG series plansifter for wheat flour mill,corn flour machine
what we offer:
- complete set 5-500t/24h wheat/corn flour milling machines
- turn-key project, including design, installation, test and training.
- one-year free spare parts
- one-year quality gurantee
- lifetime after-sales service
The process of flour milling:
The process of flour milling (from corn to milled into corn flour) usually consist of the following: 1. corn storage (silos, or warehouse)
2. Cleaning system (sifter, destoner, seprater, magnet, scourer, etc)
3. Dampening (dampener, conditioning silos, etc)
4. Milling system (roller mill, plansifter, purifier, impact detacher, etc.)
5. Flour pressure and blending system (if need)
6. Flour packing and stacking
auto-control flour roller mill
Name:FSFG series plansifter
Mian types:FSFG4×16,4×22,6×22,6×24
It is the efficient level revolving plansifter.It is composed of flour or six or eitght isolate storehouse.It can adapt to classify material under the mill of every screen according to the requirements of flour mill.The effect of screening is fine,operation is reliability,operating maintenance is convenient,low power consumption,high efficiency.It is the main plansifter for large and middle grain processing plant.
No. |
Item |
Unit |
Technical Specifications |
||||
|
FSFG4× 16 |
FSFG4× 22 |
FSFG4× 24 |
FSFG6× 24 |
FSFG8× 24 |
|||
1 |
Quatity of storhouse |
Piece |
4 |
4 |
4 |
6 |
8 |
2 |
Quatity of seive |
Piece |
16-18 |
22-24 |
24-27 |
24-27 |
24-27 |
3 |
Area of screen |
m2 |
17.9~ 25.03 |
24.7~33.37 |
26.99~ 37.54 |
40.4~ 56.31 |
53.9~ 66.73 |
4 |
Spindle Speed |
r/min |
~245 |
||||
5 |
Swing diameter |
mm |
64±1 |
||||
6 |
Lowest installation height |
mm |
2840 |
3540 |
3730 |
3730 |
3730 |
7 |
Main mill drive motor |
Y100L-6 1.5kw |
Y132S-6 3kw
|
Y132S-6 3kw
|
Y132M1-6 4kw
|
Y132M2-6 7.5kw
|
|
8 |
Direction of turning |
|
Anticlockwise |
||||
9 |
Overall dimension |
mm |
1673×2180 ×1718 |
2410×1780 ×2240 |
2410×1780 ×2430 |
2410×2550 ×2430 |
2760×3700 ×2430 |
11 |
Seive height |
mm |
1270 |
1630 |
1820 |
1820 |
1820 |
12 |
Weight |
kg |
1800 |
2500 |
2620 |
3530 |
4500 |
6FTP-50 type wheat flour milling equipment |
||
cleaning part |
Three screen, two scour, two destoner, two damper, and three magnetic separator. |
|
milling part |
seven sets of FMF50×2 Double-roller mill, four sets of Double-section high efficiency square sifter consist of the milling technology of four break, four reduction, one scratch, two bran brusher |
|
Production capacity |
50 tons of wheat/24H. |
|
Power supply |
About 140kW. |
|
Container |
40’×2 |
|
Used under |
Voltage: 380V, Frequency: 50HZ, below a elevation of 1000m. |
|
Quality guarantee period |
one year |
|
Workshop |
Triangle-framed workshop, with 36m long and 9m wide, and 8.0m under the beam. |
|
Installation expenses |
This service is the charged service, Which includes installation, test running, and training local operators. This complete equipment requires two technicians for guiding installation. The buyer should provide for technicians return tickets, local food and boarding, transportation, medical insurance, and the salary of 1,500USD per man per month. The buyer should directly pay technicians the salary.. |
|
Our services:
The single machiens for wheat flour mill/maize flour machine
Our engineers in Afirica help customer install the flour milling machine
Final products of wheat flour milling machine and corn flour mill
Contact us
If you are interested in our product, FSFG series plansifter for wheat flour mill,corn flour machine, please contact us any time, we will offer you a detailed quotation.
