Help CenterStainless Steel Dutch Woven 30*150 Mesh/wire Cloth
Related Products
-
China Plain Weave/Twill Weave/Dutch Weave Stainless Steel Net PriceUS$ 53.86 - 520.98MOQ: 1 Roll -
300 Micron 304 316 316L Stainless Steel Twill Dutch Wire MeshUS$ 53.86 - 520.98MOQ: 1 Roll
-
Plain Dutch Weave/twill Weave Stainless Steel Wire Mesh/cloth With Low Price(manufacture)US$ 53.86 - 520.98MOQ: 1 Roll
-
High Quality Stainless Steel Wire Mesh /304 316 Plain Twill Dutch Weave Filter Stainless Steel Wire MeshUS$ 53.86 - 520.98MOQ: 1 Roll
-
Gold Supplier Sus 304.304L.316.316L Plain Dutch Satinless Wire Mesh/twill Dutch Filter Wire MeshUS$ 53.86 - 520.98MOQ: 1 Roll
Material: stainless steel wire, nickel wire, brass wire.
Weaving ways: Dutch Plain Woven, Dutch Twill Woven, Reverse Dutch Woven, Five-harness Woven
plain weave :similar to twill Dutch weave, except that the weave is plain, allowing a double layer of weft wires. There are no apertures in the true sense of the word as the filtrate follows a sinuous path through the depth of the wire mesh.
Usage: this type of cloth is most frequently used for high pressure filtration processor to separate from other medium. it is widely used in industry of spaceflight, petroleum, chemical and so on.
Mesh: 20/270 to 500/3500.
Plain Dutch | |||
Gauge |
Mesh |
Wire Diameter |
Reference Values Of Darticles Passed |
40 |
10*64 |
0.55*0.42 |
260 |
50 |
12*75 |
0.45*0.35 |
220 |
80 |
24*110 |
0.35*0.25 |
160 |
100 |
25*140 |
0.28*0.20 |
100 |
120 |
30*150 |
0.25*0.18 |
80 |
140 |
35*180 |
0.20*0.16 |
70 |
160 |
40*200 |
0.18*0.13 |
60 |
180 |
45*220 |
0.16*0.12 |
56 |
200 |
50*250 |
0.15*0.11 |
50 |
240 |
60*300 |
0.14*0.09 |
45 |
260 |
65*320 |
0.13*0.08 |
36 |
280 |
70*400 |
0.125*0.07 |
34 |
300 |
80*700 |
0.11*0.039 |
32 |
Twilled Dutch | |||
Gauge |
Mesh |
Wire Diameter |
Reference Values Of Darticles Passed |
80 |
20*250 |
0.28*0.2 |
38 |
120 |
30*300 |
0.25*0.18 |
36 |
200 |
50*500 |
0.14*0.11 |
34 |
320 |
80*700 |
0.11*0.08 |
32 |
320 |
80*780 |
0.10*0.07 |
30 |
360 |
90*780 |
0.10*0.07 |
25 |
400 |
100*780 |
0.10*0.07 |
22 |
400 |
100*900 |
0.10*0.063 |
20 |
500 |
120*1100 |
0.07*0.05 |
17 |
630 |
150*1400 |
0.063*0.04 |
16 |
650 |
165*1400 |
0.07*0.04 |
14 |
685 |
180*1800 |
0.063*0.032 |
13 |
795 |
200*1400 |
0.07*0.04 |
12 |
795 |
200*1800 |
0.05*0.032 |
10 |
850 |
210*1900 |
0.045*0.03 |
10 |
1000 |
250*2000 |
0.045*0.028 |
8 |
1125 |
280*2200 |
0.036*0.026 |
7 |
1200 |
300*2200 |
0.036*0.026 |
6 |
1250 |
325*2300 |
0.035*0.025 |
5 |
1600 |
400*2800 |
0.03*0.018 |
3 |
We are producing and exporting various kinds of dutch wire mesh of all sizes and specifications and our products enjoy high popularity all over the world just because of the advanced equipment,perfect craftsmanship ,and scientific inspection skill , reasonable price ,and reliable quality!
Welcome to establish business relations with us !
We assure you we would provide the products with the best quality at the best price for you !
