Help CenterDutch Weave 24x110 Ultra Fine Woven Stainless Steel Wire Mesh
Related Products
-
Stainless Steel Ducth Wire MeshUS$ 53.86 - 520.98MOQ: 1 Roll -
304ss Stainless Steel Dutch Wire NettingUS$ 53.86 - 520.98MOQ: 1 Roll
-
Twill/dutch Stainless Steel Security Wire Mesh NettingUS$ 53.86 - 520.98MOQ: 1 Roll
-
Plain Dutch Twill Weave Stainless Steel Wire Mesh (Factory)US$ 53.86 - 520.98MOQ: 1 Roll
-
Plain Twill Dutch Filter Weave 304 Stainless Steel Wire Mesh With Competitive PriceUS$ 53.86 - 520.98MOQ: 1 Roll
Material: stainless steel wire, nickel wire, brass wire.
Weaving ways: Dutch Plain Woven, Dutch Twill Woven, Reverse Dutch Woven, Five-harness Woven
plain weave :similar to twill Dutch weave, except that the weave is plain, allowing a double layer of weft wires. There are no apertures in the true sense of the word as the filtrate follows a sinuous path through the depth of the wire mesh.
Usage: this type of cloth is most frequently used for high pressure filtration processor to separate from other medium. it is widely used in industry of spaceflight, petroleum, chemical and so on.
Mesh: 20/270 to 500/3500.
Plain Dutch | |||
Gauge |
Mesh |
Wire Diameter |
Reference Values Of Darticles Passed |
40 |
10*64 |
0.55*0.42 |
260 |
50 |
12*75 |
0.45*0.35 |
220 |
80 |
24*110 |
0.35*0.25 |
160 |
100 |
25*140 |
0.28*0.20 |
100 |
120 |
30*150 |
0.25*0.18 |
80 |
140 |
35*180 |
0.20*0.16 |
70 |
160 |
40*200 |
0.18*0.13 |
60 |
180 |
45*220 |
0.16*0.12 |
56 |
200 |
50*250 |
0.15*0.11 |
50 |
240 |
60*300 |
0.14*0.09 |
45 |
260 |
65*320 |
0.13*0.08 |
36 |
280 |
70*400 |
0.125*0.07 |
34 |
300 |
80*700 |
0.11*0.039 |
32 |
Twilled Dutch | |||
Gauge |
Mesh |
Wire Diameter |
Reference Values Of Darticles Passed |
80 |
20*250 |
0.28*0.2 |
38 |
120 |
30*300 |
0.25*0.18 |
36 |
200 |
50*500 |
0.14*0.11 |
34 |
320 |
80*700 |
0.11*0.08 |
32 |
320 |
80*780 |
0.10*0.07 |
30 |
360 |
90*780 |
0.10*0.07 |
25 |
400 |
100*780 |
0.10*0.07 |
22 |
400 |
100*900 |
0.10*0.063 |
20 |
500 |
120*1100 |
0.07*0.05 |
17 |
630 |
150*1400 |
0.063*0.04 |
16 |
650 |
165*1400 |
0.07*0.04 |
14 |
685 |
180*1800 |
0.063*0.032 |
13 |
795 |
200*1400 |
0.07*0.04 |
12 |
795 |
200*1800 |
0.05*0.032 |
10 |
850 |
210*1900 |
0.045*0.03 |
10 |
1000 |
250*2000 |
0.045*0.028 |
8 |
1125 |
280*2200 |
0.036*0.026 |
7 |
1200 |
300*2200 |
0.036*0.026 |
6 |
1250 |
325*2300 |
0.035*0.025 |
5 |
1600 |
400*2800 |
0.03*0.018 |
3 |
We are producing and exporting various kinds of dutch wire mesh of all sizes and specifications and our products enjoy high popularity all over the world just because of the advanced equipment,perfect craftsmanship ,and scientific inspection skill , reasonable price ,and reliable quality!
Welcome to establish business relations with us !
We assure you we would provide the products with the best quality at the best price for you !
