chicken laying egg cages

Specifications

chicken laying egg cages
hot dipped galvanized
Space:49x34x35cm per chicken,
manual feeder&auto water system

                   chicken laying egg cages



H.S Code : 8436290000



Name  :   cage-type L4

    Whole size  :  188cm*55cm*110cm



        Capacity  :   96 birds



              Cells  :   24 cells, 4 birds per cell



              Tiers  :   A type, 3 tiers



        Lifespan  :   Beyond 20 years because of Special Galvanizing process



          Fittings  :   Cage mesh, cage frame, feeders, auto drinking system



Galvanization  :  Firstly Welded then Special Galvanization Under high temperature zinc solution





Name  :   cage-type L2



    Whole size  :  195cm*55cm*110cm





        Capacity  :   120 birds







              Cells  :   30 cells, 4birds per cell







              Tiers  :   A type, 3 tiers







        Lifespan  :   Beyond 20 years because of Special Galvanizing process







          Fittings  :   Cage mesh, cage frame, feeders, auto drinking system







Galvanization  :  Firstly Welded then Special Galvanization Under high temperature zinc solution







1.Material:low carbon steel wire 2.5mm-3mm



2.surface treatment:electro galvanized;hot dip galvanized(high quality galvanizing improves the lifespan of cage)and green PVC coated.



3.poultry farming equipment:

1. Feed trough

2. Water pipes

3. Nipple drinker

4. Water pressure regulator

5. Cage frame

6. Installing fittings



 4.hot sale type:



Tiers : A type, 3 tiers

Cage size :188*55*37/32cm

Capacity : 4x4x6=96 birds / set ( 4 birds per cell, ,4cells per cage ,6cages per set )

Lifespan : more than 20 years for high zinc coating cage

Fittings : Cage mesh, cage frame, feeders, auto drinking system



5.chicken cage

Nets piece smooth, prevent the chicken foot injury infection. Every nets and bottom nets are encryption, can effectively prevent the peck plume pecked the anus and gossypol fatigue syndrome.



Galvanized mesh, improve service life. Unique door, door reinforcement design space increases, it will be conveniente for the chicken exercise and activity. High density raise economical use of land, which is beneficial to reduce the epidemic disease incidence rate



Categories	Specification
egg chicken cage	188cm*55cm*37cm/32cm   three layer 96 piece
brooder cage	100*60*35cm/140*70*35cm four layers
Broiler cage	140*70*40cm/188*60*30cm
Special product are available according to customer requirements.



6. Design : Please tell me your land size, we will design the layout

we can produce according to cusromers' requirement



7.surface treatment: Firstly Welded then high zinc coating or pvc coated
