Help CenterSolar Greenhouse Invernadero Ojival Economico
Related Products
-
Butterfly Roof Window Greenhouse for VegetableUS$ 8.8 - 12.88MOQ: 1 Unit -
Professional Roof Ventilation Agricultural Greenhouse Manufacturer in ChinaUS$ 5.8 - 12.8MOQ: 1 Square Meter
-
Economical Poly Greenhouse for Large Scale CultivationUS$ 5.8 - 12.8MOQ: 1 Square Meter
-
The Cheapest and Easily Installed Agricultural/ Commercial Green HouseUS$ 5.88 - 8.88MOQ: 1 Square Meter
-
Single Plastic Film Tropical Greenhouse FrameUS$ 5.8 - 12.8MOQ: 1 Square Meter
Agrotime Single- tunnel Greenhouse Advantage
- Suitable for use in even the harshest of climates
- Ideally suited for professional growers who require unique environments for different crops
- Provides economical growing space
- Specially designed swinging side vent and the double ridge vents allow for a more natural airflow
- Dramatically sloped arch design optimizes the useable space for growing bench crops as well as hanging baskets
Uses & Application
Floriculture/Vegetable Crops/Nursery Crops
Greenhouse specification:
The following diagram denotes basic terminology associated with Agrotime single tunnel framework
A Rib, Hoop, Arch, Bow
B Purlin , Ridgepole
C End Wall
D Side Wall
Greenhouse basic information
Model |
Width |
Length |
Wall Height |
Apex Height |
Cladding |
Pipe Diameter |
CMS3810 |
6m-10m |
20m-100m |
1.5m-2.2m |
2.5m-4.0m |
PEP Film. |
φ32,φ40,φ48φ58 |
Frame structure
l By the 275g/m2 hot-dipping steel pipe, 10year warranty of the frame
Metal pipe is the strongest framing material for rib construction
Covering system
l PEP film : 80micron/100micron/120mircon/150 micron/200micron
Greenhouse-grade polyethylene, a plastic film, is the most common material used for covering high tunnels
Nature ventilation
l Sky window, side window, with automatic open-close operation control, is optional
Shade Cloth system
l Shade cloth is purchased by percent light blocked, 20-90% are commonly available Seasonal and crop species
requirements dictate what percent shade cloth would be chosen
Greenhouse door
l one door or as the customer requirement
Greenhouse Film locking system
l Wiggle wire nestled in an locking channel(locking proflie) offers continuous force along the surface of plastic
and is relatively easy to install
Photo Gallery
Or contact to us directly as following
China Agrotime Ltd
Professional Greenhouse Manufacturer
Tel:86-571-63727826-810 Fax:86-571-63727821
Phone:86-15825526729 Skype: agrotimechina
Email: greenhouse (at)
Add:NO.399 Science Building Huanchen North Road Hangzhou, Zhejiang,China
Factory Add: TaiYang Industrial Zone Hangzhou Zhejiang China
