Specifications
cooling nozzle, ceramic fog nozzle, fogger nozzle, brass, 304ss and 316ssss, ceramic or ruby insert, 0.1-0.5mm
Wholesale price, ultra-fast delivery, fine quality guarantee, professional supplier, all-round technique assistance
Specification of Fog Nozzles:
1. Material of Spray orifice: ss, ceramic or ruby for selection.
2. Materials of connection body: brass, 304ss, 316ss, nickel plated brass.
3. Spray orifice diameter: 0.1mm, 0.15mm, 0.2mm, 0.3mm, 0.4mm and 0.5mm.
4. Inlet connection thread: 10/24", 12/24", 3/16" and 1/8".
RELAB produces and supplies a variety of misting system fittings with compression and slip-lock types, including the one-nozzle connector, elbow, tee, ball valve, male coupling, tubing and pump etc. These fittings can resist 10-100 bar pressure.
You are getting 100% Factory Price, welcome visit our factory in Dongguan City Of China.
| Part No. | Body Material |
Inlet Thread | Orifice Dia.(mm) | Working Pressure | Flow rate | Spray Angle |
|||
| mm | in | bar | psi | LPM | GPM | ||||
| FG10 | Brass/SS | 10/24-UNC/2A | 0.1mm | 0.004" | 20-70 | 300-1000 | 0.013-0.02 | 0.003-0.005 | 45-55 |
| FG15 | Brass/SS | 10/24-UNC/2A | 0.15mm | 0.006" | 10-70 | 150-1000 | 0.023-0.05 | 0.006-0.013 | 50-65 |
| FG20 | Brass/SS | 10/24-UNC/2A | 0.2mm | 0.008" | 10-70 | 150-1000 | 0.028-0.07 | 0.007-0.018 | 55-70 |
| FG30 | Brass/SS | 10/24-UNC/2A | 0.3mm | 0.012" | 4-70 | 60-1000 | 0.045-0.093 | 0.012-0.026 | 65-75 |
| FG40 | Brass/SS | 10/24-UNC/2A | 0.4mm | 0.016" | 4-70 | 60-1000 | 0.07-0.150 | 0.018-0.040 | 80-85 |
| FG50 | Brass/SS | 10/24-UNC/2A | 0.5mm | 0.020" | 4-70 | 60-1000 | 0.083-0.165 | 0.021-0.043 | 80-90 |
RELAB's fog nozzles can be applied for high pressure fogging system and low pressure misting system for indoor or outdoor.
System Fittings:
RELAB also supplies the push-lock/slip lock fittings of misting system kits, such as the tube, cutter, connector, tee, elbow, cross, end, clamp, water filter, ball valve, spray tips and pump, etc.
1. Slip Lock Single hole:
-- Quick coupling for tube 3/8" Ø Single hole thread 10/24 orifice
-- Quick coupling for tube 1/2" Ø Single hole thread 10/24 orifice
Slip Lock Double Holes
-- Slip Lock for tube 3/8" Ø
-- 180°Double holes thread 10/24 orifice
-- Slip Lock for tube 1/2" Ø
-- 180°Double holes thread 10/24 orifice
2. Slip Lock Tee Way:
-- Slip Lock for tube 3/8" Ø / 3/8" Ø
-- Quick bushing for tube 3/8" Ø
-- Quick coupling for tube 1/2" Ø / 1/2" Ø
-- Quick bushing for tube 1/2" Ø
-- Quick bushing for tube 1/2" Ø / 1/2" Ø
-- Quick bushing for tube 3/8" Ø
3.Slip Lock End Plug:
-- Slip Lock for tube 3/8 Ø End plug
-- Slip Lock for tube 1/2 Ø End plug
3. Slip Lock Elbow:
-- 90 degree elbow for the 3/8" tubing
4. Flexible Tubing:
--Nylon tubing of OD 3/8"(9.52mm), 120bar/1800PSI
--PE tubing of OD 3/8"(9.52mm), 70bar/1000PSI
5. Water filter:
--5" water filters for selection.
6. Cutter:
-- Special hose tubing cutter
7. Fog Machine/pump:
--0.3LPM to 22LPM, 110V/220V/380V, 50HZ/60HZ, single/three-phase voltage
Indoor Fogging System Design:
Kindly tell us your dimension of length and width and your application fields, we can propose all the parts for you to DIY misting system/fogging system within 8 hours.
RELAB has some professional engineers who are very willing to assist you to set up and design the system, if it is first time for you to design your mist cooling system or fogging system, only need tell us the dimension of spraying area and spray effect you expect.
Outdoor Misting System Kits:
RELAB supplies a complete system kit in 8m, 10m, 20m, 36m, 60m, you only need to assemble them.
Misting system and fogging system application:
agriculture, animal, industrial, outdoor, horticulture, horticulture, poultry, dairy, amusement
park, greenhouse, hotel, playground, piazza, verandah, barn and textile-factory etc.
1. How to Order?
Normally the customer can order our products by Alibaba platform or contact RELAB representative by Email. After receiving your message, our sales will confirm with you about the specification or other required things, then RELAB will send an official invoice to you via mail, which will be included the details of your order and bank information named RELAB with a stamp and signed by manager.
2. How to Pay?
We accept the payment via ESCROW, T/T (bank transfer) and Western Union, even Paypal or Credit card. Please inquire us about the details in advance.
In 2-4 working days, the payment will be transferred into our account. You can order the product directly from our web store at /store/702679 .
3. How to Deliver?
After paying, you will know a delivery time from our official invoice, the package will be sent or delivered within that schemed time. RELAB often arrange the delivery via DHL, UPS, Hong Kong Post, China Post or EMS. DHL international express is our preferred method.
In order to the package secure, RELAB doesn't deliver the package via any transport agent. We can also select other ways in that case of customer request; it is also available to ship the package as per appointed forwarder or picking it up via freight collection.
·Expedited shipping: 2-4 working days via DHL express to USA, Europe and Asia
·Standard shipping: 4-8 working days via DHL express to South of America and Africa
·Airmail: 10-30 working days
4. How to track the order?
After delivered, we will enter a tracking number on Alibaba platform; you will find and track the status of your package, or send a tracking number to your mailbox, you can track it directly at the following web.
/en/Order_Tracking.html
5. How to return?
Acceptable to the returns when you receive the products because of the following reasons.
1. Product was damaged, lost or missed
2. Different specification from required one.
Before ordering, please select a suitable product for you. As you know, all of us don't expect the return. If your return is the result of our error (you received an incorrect or defective item, etc.) we will cover the cost of return shipping. Please note that you are responsible for the cost of shipping for returns not due to our error.
6. Do you have a quality guarantee or warranty?
Yes, all our products are covered by a 12-month warranty below ordinary environment.
We choose products to sell based on their excellent designs and proven hardware reliability. So the quality is guaranteed.
If you have any difficulties whatsoever with the products, or you are dissatisfied for whatever reason, you can contact us and we will discuss the issue in an open, honest way.
