Detailed description:
As shown in Figure 1. The cold type freeze dryer of new models comprising: a control unit *1, refrigeration equipment*2 and vacuum drying equipment*3 (the refrigeration equipment*1 and vacuum drying equipment*3 are synchronous controlled. The control device*1, refrigeration equipment*2 and vacuum drying equipment*3 are separately controlled).
The utility model type new freeze dryer is combined refrigeration equipment with vacuum drying equipment together. Refrigeration equipment* 2 and vacuum drying equipment*3, these two sections can work at the same time. It’s very appropriate.
The process of operation as followingKeep the refrigeration equipment*2in low temperaturestate;
Pre-freeze material in refrigeration equipment*2;
Dehydrate material in the vacuum drying equipment, add new material into refrigeration equipment*2 at the same time.
The new models achieve in temperature reduction by use of vacuum dry storage temperature in cooling process. Moisture adsorbed to the inner wall of the housing when drying without old cold trap for water vapor. That is, no longer a alone refrigeration cold trap for saving costs of the equipment.
The shell of new vacuum drying equipment*3 is provided with a heating tube, which can be used to melt the ice during the freeze-drying process when it’s necessary.
The bottom of the vacuum drying equipment*3 is provided with an outlet for draining defrosted water during the heating process. Soit’s very easy andc onvenient for cleaning, and reduce labor intensity when cleaning.
As shown in Figure 2.The new refrigeration equipment*2 consisting of at least one shelf carts*21. Vacuum drying equipment*3 consisting of at least one vacuum tank*33.
As shown in Figure 3.Vacuum box*33 with plexiglass door*331, on top of the vacuum tank and side with tubes*332, at the bottom with adjustable feet*333. The square tube*332arechannel steel structure.
As shown in Figure 4. Top shelf carts*21aremade of stainless steel tray configuration*211, the four sides of shelf carts are stainless steel pipe*212, the bottom has a directional wheel*213.
According to the instruction, our technicists in this technical field can fully implement technical solutions within the scope of this model protection.
| model | JK-FD-0.5N | JK-FD-1N | JK-FD-5N | JK-FD-10N | JK-FD-20N | JK-FD-50N | JK-FD-100N | JK-FD-200N | |
| Dryig area(square meter) | 0.5 | 1 | 5 | 10 | 20 | 50 | 100 | 200 | |
| capacity of original material | 5KG | 10KG | 50KG | 100KG | 200KG | 500KG | 1000KG | 2000KG | |
| Tray size mm | 400/300 | 500/400/ | 800/650 | 1000/1000 | 1000/1000 | 1000/1000 | 1000/1000 | 1000/1000 | |
| Type of tray | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | Stainless steel trays or gridding plate | |
| Quantity of tray | 4 pieces | 5 pieces | 10 pieces | 10 pieces | 20 pieces | 50 pieces | 100 pieces | 200 pieces | |
| working method | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | Frozen, freeze-dried | |
| Material of container | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | |
| control method | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | Microcomputer control system, colorful LCD touch display, recording | |
| vacuum pump | Two-stage rotary vane vacuum pump | Two-stage rotary vane vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | Rotary vane vacuum pump + Roche vacuum pump | |
| working vacuum degree | ≤ 130pa | ≤130pa | ≤130pa | ≤130pa | ≤130pa | ≤130pa | ≤130pa | ≤130pa | |
| ultimate vacuum | <10pa | <10pa | <10pa | <10pa | <10pa | <10pa | <10pa | <10pa | |
| compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | Imported compressor | |
| Trays temperature | -40- 60℃ | -40- 60℃ | -40-60℃ | -40- 60℃ | -40- 60℃ | -40-60℃ | -40-60℃ | -40- 60℃ | |
| heating method of trays | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | Ceramic Heater | |
| Catch water capacity 12 hours | ≥ 5KG | ≥ 10KG | ≥ 50KG | ≥ 100KG | ≥ 200KG | ≥ 500KG | ≥ 1000KG | ≥ 2000KG | |
| defrosting metod | Electric heating | Electric heating | Electric heating | Electric heating | Electric heating | Electric heating | Electric heating | Electric heating | |
| Cold water vapor | NO NEED | NO NEED | NO NEED | NO NEED | NO NEED | NO NEED | NO NEED | NO NEED | |
| Power | Single or three-phase power | Single or three-phase power | three-phase power | three-phase power | three-phase power | three-phase power | three-phase power | three-phase power | |
| Working Temperature | ≤ 40℃ | ≤40℃ | ≤40℃ | ≤40℃ | ≤40℃ | ≤ 40℃ | ≤ 40℃ | ≤ 40℃ | |
| Rated power | 2.5kw | 3kw | 8kw | 14kw | 22.5kw | 28kw | 38kw | 55kw | |
| The general working period | 6 hour | 6hour | 6hour | 6hour | 6hour | 6hour | 6hour | 6hour | |
| Pirce | 12300USD | 15300USD | 23000USD | 43000USD | 61500USD | 100700USD | 163000USD | 240000USD |
|
